SIPLACE GEM SW Version GEM 505.01 HOST Interface Manual Page 182 of 236 ©Siemens AG, all rights reserved VID Class Format Name and Description > FeederAccessesPerPCB will be reset when a PCB reaches the corresponding …
SIPLACE GEM SW Version GEM 505.01
HOST Interface Manual
©Siemens AG, all rights reserved page 181 of 236
VID Class Format Name and Description
<U2 FeederAccessesPerPCB>
<U2 VacuumErrors>
<U2 OpticalErrors>
<U2 CoplanarityErrors>
>
....
>
FeederAccessesPerPCB will be reset when a PCB
reaches the corresponding processing conveyor.
If the component was picked up from a feeder Level
and Tower will contain -1.
In the case that the component was picked up from a
tray in the matrix tray changer TrackNumber will be -1
and Level and Tower are valid.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
2012039 SV L PICKUPERRORSLOC3
Pick-Up Errors of location 3 (see 1.6 machine areas).
This data item will be reset when a new Process
Program is downloaded to a SIPLACE machine for the
corresponding processing area and
a PCB reaches
the corresponding processing conveyor:
processing 1 area (S25)
processing 2 area (HS50)
processing 2 area (HF).
<L
<L
<A ComponentName>
<I2 TrackNumber>
<U2 FeederType>
<I2 Level>
<I2 Division>
<U1 Tower>
<U2 FeederAccessesPerPCB>
<U2 VacuumErrors>
<U2 OpticalErrors>
<U2 CoplanarityErrors>
>
....
SIPLACE GEM SW Version GEM 505.01 HOST Interface Manual
Page 182 of 236 ©Siemens AG, all rights reserved
VID Class Format Name and Description
>
FeederAccessesPerPCB will be reset when a PCB
reaches the corresponding processing conveyor.
If the component was picked up from a feeder Level
and Tower will contain -1.
In the case that the component was picked up from a
tray in the matrix tray changer TrackNumber will be -1
and Level and Tower are valid.
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
2012040 SV L PICKUPERRORSLOC4
Pick-Up Errors of location 4 (see 1.6 machine areas).
This data item will be reset when a new Process
Program is downloaded to a SIPLACE machine for the
corresponding processing area and
a PCB reaches
the corresponding processing conveyor:
processing 1 area (S25)
processing 1 area (HS50)
processing 1 area (HF).
<L
<L
<A ComponentName>
<I2 TrackNumber>
<U2 FeederType>
<I2 Level>
<I2 Division>
<U1 Tower>
<U2 FeederAccessesPerPCB>
<U2 VacuumErrors>
<U2 OpticalErrors>
<U2 CoplanarityErrors>
>
....
>
FeederAccessesPerPCB will be reset when a PCB
reaches the corresponding processing conveyor.
If the component was picked up from a feeder Level
and Tower will contain -1.
In the case that the component was picked up from a
tray in the matrix tray changer TrackNumber will be -1
and Level and Tower are valid.
SIPLACE GEM SW Version GEM 505.01
HOST Interface Manual
©Siemens AG, all rights reserved page 183 of 236
VID Class Format Name and Description
For a detailed description of the data item see „4.2
Data Item Dictionary“.
An empty list indicates an error.
2012041 SV A PICKUPDATARESETPOINTLOC1
Date and time when the „Pick-Up Error“ data item of
Location 1 was reset.
An empty text indicates an error.
2012042 SV A PICKUPDATARESETPOINTLOC2
Date and time when the „Pick-Up Error“ data item of
Location 2 was reset.
An empty text indicates an error.
2012043 SV A PICKUPDATARESETPOINTLOC3
Date and time when the „Pick-Up Error“ data item of
Location 3 was reset.
An empty text indicates an error.
2012044 SV A PICKUPDATARESETPOINTLOC4
Date and time when the „Pick-Up Error“ data item of
Location 4 was reset.
An empty text indicates an error.
2012046 DV L TAPE_INFO
<L
<A ComponentName>
<A CompBarcode1>
<A CompBarcode2>
<A CompBarcode3>
<A CompBarcode4>
<A CompBarcode5>
<A CompBarcode6>
<U4 CompContainerSize>
>
Barcode information of a tape. Used for traceability.
2012047 DV A TABLE_ID
<A Table Barcode>
ID of a table scanned by the operator
2012048 DV U1 TOWER_ID
<U1 Tower Number>
Traceability
2512001 DV L TRACE_PCB_DATA
