SIPLACE GEM SW Version GEM 505.01 HOST Interface Manual
Page 186 of 236 ©Siemens AG, all rights reserved
7 Predefined Reports
RPTID Name VIDs
0 Clock 1002022<CLOCK>
1 Name and Clock , 1002022<CLOCK>,
1002001<GEMEVENTTEXT>
2 Not used
3 Not used
4 Transport 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
612007<TRANSPORTWIDTH>, 612008
<TWINTRANSPORTWIDTH>
5 PlaceHead1 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
1312003< PLACEINFO1>
6 PlaceHead2 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
1412003< PLACEINFO2>
7 Not used
8 PickHead1 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
1312004< PICKUPINFO1>
9 PickHead2 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
1412004< PICKUPINFO2>
10 Not used
11 Not used
12 Not used
13 Fiducial 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
412002< FIDUCIALDATA>, 2012029
<GANTRYGROUPID>, 2012028<GANTRYID>,
2012030<HEADID>,
14 Nozzle1 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
1312005< NOZZLECONF1>
15 Nozzle2 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
1412005< NOZZLECONF2>
16 Not used
17 Not used
18 Not used
19 RefRunHead1 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
1312001< HEIGHTHEAD1>
20 RefRunHead2 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
1412001< HEIGHTHEAD2>
21 RefRunVac1 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
1312006< VACUUMDATA1>
22 RefRunVac2 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
1412006 <VACUUMDATA2>
23 Firmware 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
1002054< SOFTWAREREVTABLE>,
SIPLACE GEM SW Version GEM 505.01
HOST Interface Manual
©Siemens AG, all rights reserved page 187 of 236
RPTID Name VIDs
1002071<SOFTWAREREVMTC>
24 Barcode 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
912002< BCININPUTCONVEYOR>,
912005<PCBSIDEININPUTCONVEYOR>
25 Not used
26 Not used
27 BeBarcode 1002001<GEMEVENTTEXT>,
1002022<CLOCK>,
912003<COMPONENTBARCODE>,
912004<WAYOFINPUTCOMPONENTBARCODE>
, 2012035<LOCATION>,
2012023<TRACKNUMBER>,
2012024<DIVISION>, 2012025<LEVEL
>,
2012046<TAPE_INFO>,
28 PickupError 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
2012026<SEGMENT>,
2012027<COMPONENTNAME>,
2012035<LOCATION>,
2012023<TRACKNUMBER>,
2012024<DIVISION>, 2012025<LEVEL>,
2012028<GANTRYID>,
2012029<GANTRYGROUPID>,
2012030<HEADID>
29 PlaceError 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
2012026<SEGMENT>,
2012031<REFERENCEDESIGNATOR>,
2012027<COMPONENTNAME>,
2012028<GANTRYID>,
2012029<GANTRYGROUPID>,
2012030<HEADID>
2012032<PACKAGEFORMNUMBER>,
2012033<PLACEERRORDESCRIPTION>
30 BarcodeTwin 1002022<CLOCK>, 1002022<CLOCK>,
912012<BCINTWININPUTCONVEYOR>,
912015<PCBSIDEINTWININPUTCONVEYOR>
31 GantryInfoArea1 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
1312002<GANTRYINFO1>,
2412002<GANTRYINFO4>
32 GantryInfoArea2 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
1412002<GANTRYINFO2>,
2312002<GANTRYINFO3>
33 PlaceHead3 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
2312003< PLACEINFO3>
34 PlaceHead4 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
2412003< PLACEINFO4>
35 Nozzle3 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
2312005< NOZZLECONF3>
36 Nozzle4 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
2412005< NOZZLECONF4>
SIPLACE GEM SW Version GEM 505.01 HOST Interface Manual
Page 188 of 236 ©Siemens AG, all rights reserved
RPTID Name VIDs
37 RefRunHead3 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
2312001< HEIGHTHEAD3>
38 RefRunHead4 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
2412001< HEIGHTHEAD4>
39 RefRunVac3 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
2312006< VACUUMDATA3>
40 RefRunVac4 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
2412006 <VACUUMDATA4>
41 MTCInfo 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
812002 <MTCINFO>
42 PickHead3 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
2312004< PICKUPINFO3>
43 PickHead4 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
2412004< PICKUPINFO4>
44 Errorinfo 1002001<GEMEVENTTEXT>, 1002022<CLOCK>,
1002069<LASTERROR_CODE>, 1002070
<LASTERRORTEXT>
45 GuiMessage 1002001<GEMEVENTTEXT>,
1002022<CLOCK>,
1122007<GUIMESSAGENUMBER>
46 TraceData 1002001<GEMEVENTTEXT>,
1002022<CLOCK>,
2512001<TRACE_PCB_DATA>,
2512002<TRACE_ALL_COMPONENTS>,
2512003<TRACE_SINGLE_CIRCUIT>
47 SpliceDetect 1002001<GEMEVENTTEXT>,
1002022<CLOCK, 2012047<TABLE_ID>,
2012035<LOCATION>,
2012023<TRACKNUMBER>,
2012024<DIVISION>, 2012025<LEVEL
>
Report numbers 1000 - 1100 are reserved for internal use.
