SIPLACE GEM SW Version GEM 505.01 HOST Interface Manual Page 196 of 236 ©Siemens AG, all rights reserved CEID Name Description work* 311021 FM_D_TOL_BIT Undefined error message 311023 FM_X_TIMEOUT 59 X axis: does not rea…
SIPLACE GEM SW Version GEM 505.01
HOST Interface Manual
©Siemens AG, all rights reserved page 195 of 236
CEID Name Description
PO_UEB_ABL
pos. overshot)
211062
FM_GUI_TEXT_PPW_SP_Z_SOLL
PO_N_ER_ABL
RV nozzle returning incomplete (z-
pos. not reached)
211063
FM_GUI_TEXT_PPW_SP_PINOLE
_GEZOGEN
Nozzle changer: sleeve in extended
positio
211064
FM_GUI_TEXT_PPW_VAK_ABL
Problem with vacuum reference value
upon returning nozzle
211065
FM_GUI_TEXT_PPW_VAK_ABW
Problem with vacuum reference value
upon rejecting nozzle
211066
FM_GUI_TEXT_PPW_PINOLE_
LEER
Problem returning nozzle: segment
empty
211067
FM_GUI_TEXT_PPW_PINOLE_
VOLL
Problem picking up nozzle: segment
occupied
211068
FM_GUI_TEXT_PPW_ALLE_
PINOLEN_LEER
Problem returning nozzles: all
segments empty
211069
FM_GUI_TEXT_PPW_ALLE_
PINOLEN_VOLL
Problem picking up nozzles: all
segments occupied
* Depending on the collection event, some of the status variables <ERRORTYPE>,
<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,
<ERRORINFO1> and <ERRORINFO2> will be updated at each of these nozzle
changer collection events.
Axis
CEID Name Description
311004 FM_X_N_OBEN Undefined error message
311005 FM_Y_N_OBEN Undefined error message
311006 FM_S_N_OBEN Undefined error message
311007 FM_D_N_OBEN Undefined error message
311011 FM_X_PROG_FEHLER Programmed position of X-axis
outside travel range*
311012 FM_Y_PROG_FEHLER Programmed position of Y-axis
outside travel range*
311013 FM_D_PROG_FEHLER Programmed position of D1 axis
outside travel range*
311015 FM_S_PROG_FEHLER Programmed position of S/Z-axis
outside travel range*
311017 FM_X_TOL_BIT Position control of X-axis does not
work*
311018 FM_Y_TOL_BIT Position control of Y-axis does not
work*
311019 FM_S_TOL_BIT Position control of S-axis does not
SIPLACE GEM SW Version GEM 505.01 HOST Interface Manual
Page 196 of 236 ©Siemens AG, all rights reserved
CEID Name Description
work*
311021 FM_D_TOL_BIT Undefined error message
311023 FM_X_TIMEOUT 59 X axis: does not reach required
position*
311024 FM_Y_TIMEOUT 60 Y axis: does not reach required
position*
311025 FM_S_TIMEOUT 38 S axis: does not reach required
position*
311026 FM_Z_SP_TIMEOUT 61 SP/Z axis: does not reach
required position*
311027 FM_D_TIMEOUT 8 SP/D axis: does not reach required
position*
311033 FM_Z_SP_TIMEOUT_PROXIMI
TY SWITCH
20 SP/Z axis: top Proximity switch
does not respond*
311040 FM_Z_SP_PROXIMITY
SWITCH_NICHT_FREI
SP/Z axis: top Proximity switch is not
released*
311044 FM_X_POS_PROXIMITY
SWITCH
X axis: Proximity switch for position
monitoring is off*
311045 FM_Y_POS_PROXIMITY
SWITCH
Y axis: Proximity switch for position
monitoring is off*
311046 FM_S_POS_PROXIMITY
SWITCH
S axis: Proximity switch for position
monitoring is off*
311047 FM_Z_SP_POS_PROXIMITY
SWITCH
SP/Z axis: Proximity switch for
position monitoring is off*
311048 FM_D_POS_PROXIMITY
SWITCH
SP/D axis: Proximity switch for
position monitoring is off*
311051 FM_X_ERROR_BIT X axis: Error bit set*
311052 FM_Y_ERROR_BIT Y axis: Error bit set*
311053 FM_S_ERROR_BIT S axis: Error bit set*
311054 FM_Z_SP_ERROR_BIT SP/Z axis: Error bit set*
311055 FM_D_ERROR_BIT SP/D axis: Error bit set*
311058 FM_X_WARTE_DAIN X axis: No DAIN acknowledgment*
311059 FM_Y_WARTE_DAIN Y axis: No DAIN acknowledgment*
311060 FM_S_WARTE_DAIN S axis: No DAIN acknowledgment*
311061 FM_Z_SP_WARTE_DAIN SP/Z axis: No DAIN acknowledgment*
311062 FM_D_WARTE_DAIN SP/D axis : No DAIN
acknowlegdment*
311086 FM_X_AK_UNG X axis: command currently invalid*
311087 FM_Y_AK_UNG Y axis: command currently invalid*
311088 FM_S_AK_UNG S axis: command currently invalid*
311089 FM_Z_SP_AK_UNG SP/Z axis: command currently invalid*
SIPLACE GEM SW Version GEM 505.01
HOST Interface Manual
©Siemens AG, all rights reserved page 197 of 236
CEID Name Description
311090 FM_D_AK_UNG SP/D axis: command currently invalid*
311093 FM_X_AK_UNDEF X axis: command not defined*
311094 FM_Y_AK_UNDEF Y axis: command not defined*
311095 FM_S_AK_UNDEF S axis: command not defined*
311096 FM_Z_SP_AK_UNDEF SP/Z axis: command not defined*
311097 FM_D_AK_UNDEF SP/D axis: command not defined*
311100 FM_X_POSART_UNDEF X axis: positioning type not defined*
311101 FM_Y_POSART_UNDEF Y axis: positioning type not defined*
311102 FM_S_POSART_UNDEF S axis: positioning type not defined*
311103 FM_Z_SP_POSART_UNDEF SP/Z axis: positioning type not
defined*
311104 FM_D_POSART_UNDEF SP/D axis: positioning type not
defined*
311107 FM_X_VERFAHRBEREICH X axis: destination position outside
travel range*
311108 FM_Y_VERFAHRBEREICH Y axis: destination position outside
travel range*
311109 FM_S_VERFAHRBEREICH S axis: destination position outside
travel range*
311110 FM_Z_SP_VERFAHRBEREICH SP/Z axis: destination position outside
travel range*
311111 FM_D_VERFAHRBEREICH SP/D axis: destination position
outside travel range*
311114 FM_X_REFMODE_UNDEF X axis: reference point type not
defined*
311115 FM_Y_REFMODE_UNDEF X axis: reference point type not
defined*
311116 FM_S_REFMODE_UNDEF S axis: reference point type not
defined*
311117 FM_Z_SP_REFMODE_UNDEF SP/Z axis: reference point type not
defined*
311118 FM_D_REFMODE_UNDEF SP/D axis: reference point type not
defined*
311121 FM_X_ZAEHLFEHLER X axis: counting error*
311122 FM_Y_ZAEHLFEHLER Y axis: counting error*
311123 FM_S_ZAEHLFEHLER S axis: counting error*
311124 FM_Z_SP_ZAEHLFEHLER SP/Z axis: counting error*
311125 FM_D_ZAEHLFEHLER SP/D axis: counting error*
311128 FM_X_REF_NICHT_GEF X axis: correct zero pulse not found*
311129 FM_Y_REF_NICHT_GEF Y axis: correct zero pulse not found*
311130 FM_S_REF_NICHT_GEF S axis: correct zero pulse not found*
