SIPLACE GEM SW Version GEM 505.01 HOST Interface Manual

CEID Name Description

(lead) *

511040 FM_OPT_LAGE_X_TOL_G Component outside feed tolerance

(grid) *

511041 FM_OPT_LAGE_X_TOL_B Component outside feed tolerance

(ball) *

511042 FM_OPT_LAGE_Y_TOL_DEF Component outside feed tolerance*

511043 FM_OPT_LAGE_Y_TOL_S Component outside feed tolerance

(size) *

511044 FM_OPT_LAGE_Y_TOL_R Component outside feed tolerance

(row) *

511045 FM_OPT_LAGE_Y_TOL_C Component outside feed tolerance

(corner) *

511046 FM_OPT_LAGE_Y_TOL_L Component outside feed tolerance

(lead) *

511047 FM_OPT_LAGE_Y_TOL_B Component outside feed tolerance

(ball) *

511048 FM_OPT_LAGE_Y_TOL_G Component outside feed tolerance

(grid) *

511049 FM_OPT_QUAL_FAKTOR_DEF Quality too low during optical

centering*

511050 FM_OPT_QUAL_FAKTOR_S Quality too low during opt. centering

(s) *

511051 FM_OPT_QUAL_FAKTOR_R Quality too low during opt. centering

(r) *

511052 FM_OPT_QUAL_FAKTOR_C Quality too low during opt. centering

511053 FM_OPT_QUAL_FAKTOR_L Quality too low during opt. centering

(l) *

511054 FM_OPT_QUAL_FAKTOR_G Quality too low during opt. centering

(g) *

511055 FM_OPT_QUAL_FAKTOR_B Quality too low during opt. centering

(b) *

511056 FM_OPT_DIM_L_TOL_DEF Component length outside tolerance*

511057 FM_OPT_DIM_L_TOL_S Component length outside tolerance

(s) *

511058 FM_OPT_DIM_L_TOL_R Component length outside tolerance

(r) *

511059 FM_OPT_DIM_L_TOL_C Component length outside tolerance

511060 FM_OPT_DIM_L_TOL_L Component length outside tolerance

(l) *

511061 FM_OPT_DIM_L_TOL_G Component length outside tolerance

(g) *

511062 FM_OPT_DIM_L_TOL_B Component length outside tolerance

SIPLACE GEM SW Version GEM 505.01

HOST Interface Manual

CEID Name Description

(b) *

511063 FM_OPT_DIM_B_TOL_DEF Component width outside tolerance*

511064 FM_OPT_DIM_B_TOL_S Component width outside tolerance

(s) *

511065 FM_OPT_DIM_B_TOL_R Component width outside tolerance

(r) *

511066 FM_OPT_DIM_B_TOL_C Component width outside tolerance

511067 FM_OPT_DIM_B_TOL_L Component width outside tolerance

(l) *

511068 FM_OPT_DIM_B_TOL_G Component width outside tolerance

(g) *

511069 FM_OPT_DIM_B_TOL_B Component width outside tolerance

(b) *

511070 FM_OPT_BEIN_ANZAHL_DEF Number of pins on component not

correct*

511071 FM_OPT_BEIN_ANZAHL_C Number of pins on component not

correct(c) *

511072 FM_OPT_BEIN_ANZAHL_L Number of pins on component not

correct(l) *

511073 FM_OPT_ORTHOGONALITAE

T_DEF

Orthogonality error during component

meas. *

511074

FM_OPT_ORTHOGONALITAET_C

Orthogonality error during cmpt.

meas. (c) *

511075

FM_OPT_ORTHOGONALITAET_L

Orthogonality error during cmpt.

meas. (l) *

511076

FM_OPT_WINKEL_FEHLER_DEF

Component angle outside tolerance*

511077 FM_OPT_WINKEL_FEHLER_S Component angle outside tolerance

(s) *

511078 FM_OPT_WINKEL_FEHLER_R Component angle outside tolerance

(r) *

511079 FM_OPT_WINKEL_FEHLER_C Component angle outside tolerance

511080 FM_OPT_WINKEL_FEHLER_L Component angle outside tolerance (l)

511081 FM_OPT_WINKEL_FEHLER_G Component angle outside tolerance

(g) *

511082 FM_OPT_WINKEL_FEHLER_B Component angle outside tolerance

(b) *

511083 FM_OPT_POS_NK_DEF Position: component outside feed

tolerance*

511084 FM_OPT_POS_NK_S Position: component outside feed tol

(s) *

511085 FM_OPT_POS_NK_R Position: component outside feed tol

SIPLACE GEM SW Version GEM 505.01 HOST Interface Manual

CEID Name Description

(r) *

511086 FM_OPT_POS_NK_C Position: component outside feed tol

511087 FM_OPT_POS_NK_L Position: component outside feed tol

(l) *

511088 FM_OPT_POS_NK_G Position: component outside feed tol

(g) *

511089 FM_OPT_POS_NK_B Position: component outside feed tol

(b) *

511090 FM_OPT_POS_NV_DEF Position: evaluation not possible*

511091 FM_OPT_POS_NV_S Position: evaluation not possible (s) *

511092 FM_OPT_POS_NV_R Position: evaluation not possible (r) *

511093 FM_OPT_POS_NV_C Position: evaluation not possible (c) *

511094 FM_OPT_POS_NV_L Position: evaluation not possible (l) *

511095 FM_OPT_POS_NV_G Position: evaluation not possible (g) *

511096 FM_OPT_POS_NV_B Position: evaluation not possible (b) *

511097 FM_OPT_POS_NR_DEF Position: no result*

511098 FM_OPT_POS_NR_S Position: no result (s) *

511099 FM_OPT_POS_NR_R Position: no result (r) *

511100 FM_OPT_POS_NR_C Position: no result (c) *

511101 FM_OPT_POS_NR_G Position: no result (g) *

511102 FM_OPT_POS_NR_L Position: no result (l) *

511103 FM_OPT_POS_NR_B Position: no result (b) *

511104 FM_OPT_DIM_NV_DEF Dimension: evaluation not possible*

511105 FM_OPT_DIM_NV_S Dimension: evaluation not possible

(s) *

511106 FM_OPT_DIM_NV_R Dimension: evaluation not possible

(r) *

511107 FM_OPT_DIM_NV_C Dimension: evaluation not possible (c)

511108 FM_OPT_DIM_NV_L Dimension: evaluation not possible (l)

511109 FM_OPT_DIM_NV_G Dimension: evaluation not possible (g)

511110 FM_OPT_DIM_NV_B Dimension: evaluation not possible (b)

511111 FM_OPT_BEIN_NV_DEF No. of pins: evaluation not possible*

511112 FM_OPT_BEIN_NV_C No. of pins: evaluation not possible (c)

511113 FM_OPT_BEIN_NV_L No. of pins: evaluation not possible (l)
