SIPLACE GEM SW Version GEM 505.01
HOST Interface Manual
©Siemens AG, all rights reserved page 215 of 236
CEID Name Description
„Single Function“
1000015 SingleFunction2Init The Siplace change its
processing state from
„Single Function“ to
„Machine Initialization“
1
1000020 Proc1PPChangeEvent Board with a new
processing program enters
Processing 1 Area
1
1000021 Proc2PPChangeEvent Board with a new
processing program enters
Processing 2 Area
1
Process Program Management
1000017 GemBadDownloadEvent Error in downloaded
program
1
1001018 FM_GEM_INIT GEM: Error upon
initialization of GEM
interface to host*
1001019 FM_GEM_INIT_MC GEM: Error upon
initialization of interface to
MC*
1001020 FM_GEM_INIT_GUI GEM: Error upon
initialization of interface to
user interface*
1001021 FM_GEM_SIPLACE GEM: Error in SIPLACE
GEM software*
1001022 FM_GEM_OP_MELDUNG GEM: Most recent operator
message could not be sent
to the host*
1001023 FM_GEM_VERB_GUI GEM: Faulty connection
between GEM interface
and user interface*
1001024 FM_GENERAL General Error Event
Error messages can be
reported either with specific
error events (an Error
Event with a CEID for each
individual error) or with the
General Error Event that
reports all errors.
The General Error Event
has an error code
<LASTERRORCODE>,
which contains the CEID of
the specific Error Event.
The SV <LASTFMTEXT>
which contains the error
text of the specific Error
Event is also available.
44
SIPLACE GEM SW Version GEM 505.01 HOST Interface Manual
Page 216 of 236 ©Siemens AG, all rights reserved
* Depending on the collection event, some of the status variables <ERRORTYPE>,
<GANTRYONERROR>, <SEGMENTONERROR>, <TRACKONERROR>,
<ERRORINFO1> and <ERRORINFO2> will be updated at each of these GEM-
kernel collection events.
Operator
CEID Name Description
1120001 EmergencyStop Emergency stop pressed or Cover
opened
1
1120002 StopButton Stop button pressed 1
1120003 StartButton Start button pressed 1
1120007 GUIStart Message from GUI: Start. 1
1120008 GUISTOP Message from GUI: Stop. 1
1120009 GUIContinue Message from GUI: Continue. 1
1120010 GUIAbort Message from GUI: Abort. 1
1120096 ToGUINewSetUp Message to GUI: NewSetUp 1
1120097 ToGUIPPname Message to GUI: Placement
Program Name
1
1120098 ToGUIActionText Message to GUI: Send
<GUIACTIONTEXT>
1
1120100 ToGUIStateText Message to GUI: Send
<GUISTATETEXT>
1
1120103 ToGUIMachineReady Message to GUI: Machine ready to
process
1
1120104 ToGUIStopButton Message to GUI: Stop button
pressed
1
1120105 ToGUIEmergencyButton Message to GUI: Emergency button
pressed
1
1120117 ToGUIBarcodeError Message to GUI: PCB-Barcode
error
1
1120216 ToGUICtrlModeChanged Control Mode change (Stand-alone,
GEM-Host or LCU) is completed.
1
1120258 ToGUIRefRunReady Machine is ready to start reference
run
1
1120259 ToGUInewjobname display new jobname 1
1120300 MessageFromGuiGeneral General Event for all Messages
from GUI
Messages from GUI can be reported
either with specific events (one
event with one CEID for each
individual message) or with the
Event MessageFromGuiGeneral.
The variable 1122007
<GUIMESSAGENUMBER >
contains the CEID of the specific
GUI message.
45
SIPLACE GEM SW Version GEM 505.01
HOST Interface Manual
©Siemens AG, all rights reserved page 217 of 236
CEID Name Description
1120301 MessageToGuiGeneral General Event for all Messages to
GUI
Messages to GUI can be reported
either with specific events (one
event with one CEID for each
individual message) or with the
Event MessageToGuiGeneral.
The variable 1122007 <
GUIMESSAGENUMBER> contains
the CEID of the specific Message
To Gui.
45
CAN-Bus
CEID Name Description
1211001 FM_CAN_INI_APL CAN bus: Initialization faulty*
1211002 FM_CAN_SND_OVL CAN bus: transmission source
overflow*
1211003 FM_CAN_NO_CAR CAN bus: reception job before
transmission job*
1211004 FM_CAN_RCV_TOUT CAN bus: reception call aborted
with timeout*
1211005 FM_CAN_RCV_OVR CAN bus: reception source
overflow*
1211006 FM_CAN_CNT_EXL CAN bus: error hysteresis counter
exceeded*
1211007 FM_CAN_BUS_OFF CAN bus: switched out*
1211008
FM_CAN_FHL_NR_UNBEKANNT
CAN bus: unknown error number*
1211013
FM_CAN_MSG_LS_ZHS_FALSE
Star can't be turned due to light
barrier z-top*
1211014
FM_CAN_MSG_SM_DPS_FALSE
Star can't be turned due to d-axis
feed drive*
1211015
FM_CAN_MSG_SM_ZHS_FALSE
Star can't be turned due to pick-
up/place valve actuator*
1211016
FM_CAN_MSG_SM_BAS_FALSE
Star can't be turned due to ejection
valve actuator*
1211017 FM_CAN_MSG_LS_ZHS_
START_XY
RV: Gantry can't be moved due to
light barrier z-top*
1211019 FM_CAN_MSG_ZHS_ABH RV: Fault in pick-up/place valve
actuator during pick-up*
1211020 FM_CAN_MSG_LS_Z_O_ABH_
SP
RV: Light barrier z-top not
triggered during pick-up*
1211022 FM_CAN_MSG_ZHS_BST RV: Fault in pick-up/place valve
