SIPLACE GEM SW Version GEM 505.01 HOST Interface Manual Page 218 of 236 ©Siemens AG, all rights reserved CEID Name Description actuator during placement* 1211023 FM_CAN_MSG_LS_Z_O_BST_ SP RV: Light barrier z-top not trig…

SIPLACE GEM SW Version GEM 505.01

HOST Interface Manual

CEID Name Description

1120301 MessageToGuiGeneral General Event for all Messages to

GUI

Messages to GUI can be reported

either with specific events (one

event with one CEID for each

individual message) or with the

Event MessageToGuiGeneral.

The variable 1122007 <

GUIMESSAGENUMBER> contains

the CEID of the specific Message

To Gui.

CAN-Bus

CEID Name Description

1211001 FM_CAN_INI_APL CAN bus: Initialization faulty*

1211002 FM_CAN_SND_OVL CAN bus: transmission source

overflow*

1211003 FM_CAN_NO_CAR CAN bus: reception job before

transmission job*

1211004 FM_CAN_RCV_TOUT CAN bus: reception call aborted

with timeout*

1211005 FM_CAN_RCV_OVR CAN bus: reception source

overflow*

1211006 FM_CAN_CNT_EXL CAN bus: error hysteresis counter

exceeded*

1211007 FM_CAN_BUS_OFF CAN bus: switched out*

1211008

FM_CAN_FHL_NR_UNBEKANNT

CAN bus: unknown error number*

1211013

FM_CAN_MSG_LS_ZHS_FALSE

Star can't be turned due to light

barrier z-top*

1211014

FM_CAN_MSG_SM_DPS_FALSE

Star can't be turned due to d-axis

feed drive*

1211015

FM_CAN_MSG_SM_ZHS_FALSE

Star can't be turned due to pick-

up/place valve actuator*

1211016

FM_CAN_MSG_SM_BAS_FALSE

Star can't be turned due to ejection

valve actuator*

1211017 FM_CAN_MSG_LS_ZHS_

START_XY

RV: Gantry can't be moved due to

light barrier z-top*

1211019 FM_CAN_MSG_ZHS_ABH RV: Fault in pick-up/place valve

actuator during pick-up*

1211020 FM_CAN_MSG_LS_Z_O_ABH_

RV: Light barrier z-top not

triggered during pick-up*

1211022 FM_CAN_MSG_ZHS_BST RV: Fault in pick-up/place valve

SIPLACE GEM SW Version GEM 505.01 HOST Interface Manual

CEID Name Description

actuator during placement*

1211023 FM_CAN_MSG_LS_Z_O_BST_

RV: Light barrier z-top not

triggered during placement*

1211025 FM_CAN_MSG_VAKUUM_

MESS_SP

RV: vacuum cannot be measured

1211026

FM_CAN_MSG_BLASL_MESS_SP

RV: forced air cannot be measured

1211027

FM_CAN_MSG_VAKUUM_AUS_SP

RV: vacuum cannot be switched

off

1211028

FM_CAN_MSG_VAKUUM_EIN_SP

RV: vacuum cannot be switched

1211029

FM_CAN_MSG_BLASL_EIN_SP

RV: forced air cannot be switched

1211030

FM_CAN_MSG_BLASL_AUS_SP

RV: forced air cannot be switched

off

1211031 FM_CAN_MSG_INIT_Z Valve adjustment drive pick-

up/placement cannot be initialized

1211032 FM_CAN_MSG_INIT_D RV/D axis: feeder drive cannot be

initialized

1211033 FM_CAN_MSG_INIT_ABW Valve adjustment drive ejection

cannot be initialized

1211034 FM_CAN_MSG_BELEUCHT_BE

_SP

RV: component camera

illumination cannot be operated

1211037 FM_CAN_MSG_BELEUCHT_LP Board camera illumination cannot

be operated

1211038 FM_CAN_MSG_FHL_NR_

UNBEK_SP

RV: unknown error number from

head board

1211039 FM_GUI_TEXT_TI_CCAN_NO_

SYNC_CALL

System error in CAN

communication (CCAN_NOK)

1211040 FM_GUI_TEXT_TI_CCANDL_

NO_SYNC_CALL

System error in CAN

communication (CCANDL_NOK)

1211041

FM_GUI_TEXT_TI_CAN_M_NOK

Component table: Error in

communication with CAN bus (no

status signal)

1211042

FM_GUI_TEXT_TI_CAN_M_BUSY

Component table: Error in

communication with CAN bus

(overload)

1211043

FM_GUI_TEXT_TI_CAN_M_TIME_

OUT

Component table: Error in

communication with CAN bus

(timeout)

1211044 FM_GUI_TEXT_TI_CAN_M_NO

_PROG

Component table: Error in

communication with CAN bus (no

program)

1211045 FM_GUI_TEXT_TI_CAN_M_CM

D_FALSE

Component table: Error in

communication with CAN bus

SIPLACE GEM SW Version GEM 505.01

HOST Interface Manual

CEID Name Description

(incorrect command)

1211046 FM_GUI_TEXT_TI_CAN_M_NO

_TARGET

Component table: Error in

communication with CAN bus

(incorrect receiver)

1211047 FM_GUI_TEXT_TI_CAN_WRON

G_QUITT

Component table: Unknown

acknowledgment from CAN bus

1211048 FM_GUI_TEXT_TI_CAN_WR_Q

UITT_L

Component table: Incorrect length

of acknowledgment message from

CAN bus

1211049 FM_GUI_TEXT_TI_CCAN_NO_

NORM

System error (CCAN_NO_NORM)

1211050 FM_GUI_TEXT_TI_CCAN_NO_

VIRT

System error (CCAN_NO_VIRT)

1211051

FM_GUI_TEXT_GS_CAN_M_NOK

Tape cutting unit: Error in

communication with CAN bus (no

status signal)

1211052

FM_GUI_TEXT_GS_CAN_M_BUSY

Tape cutting unit: Error in

communication with CAN bus

(overload)

1211053 FM_GUI_TEXT_GS_CAN_M_TI

ME_OUT

Tape cutting unit: Error in

communication with CAN bus

(timeout)

1211054 FM_GUI_TEXT_GS_CAN_M_N

O_PROG

Tape cutting unit: Error in

communication with CAN bus (no

program)

1211055 FM_GUI_TEXT_GS_CAN_M_C

MD_FALSE

Tape cutting unit: Error in

communication with CAN bus

(incorrect command)

1211056 FM_GUI_TEXT_GS_CAN_M_N

O_TARGET

Tape cutting unit: Error in

communication with CAN bus

(incorrect command)

1211057 FM_GUI_TEXT_GS_CAN_WRO

NG_QUITT

Tape cutting unit: Unknown

acknowledgment from CAN bus

1211058 FM_GUI_TEXT_GS_CAN_WR_

QUITT_L

Tape cutting unit: Incorrect length

of acknowledgment message from

CAN bus

1211060 FM_GUI_TEXT_CAN_NO_SLIO System error (CAN_NO_SLIO)

1211061 FM_GUI_TEXT_CAN_SLIO_NO

_RESPONSE

System error

(CAN_SLIO_NO_RESPONSE)

1211062 FM_GUI_TEXT_CAN_ABORT_E

RROR

System error

(CAN_ABORT_ERROR)

1211063 FM_GUI_TEXT_CAN_SETOUTP

UTBITS

System error

(CAN_SETOUTPUTBITS)

1211064 FM_GUI_TEXT_CAN_RESETO

UTPUTBITS

System error

(CAN_RESETOUTPUTBITS)

1211065 FM_GUI_TEXT_CAN_PIN_BLIN System error
