SIPLACE GEM SW Version GEM 505.01
HOST Interface Manual
©Siemens AG, all rights reserved page 227 of 236
CEID Name Description
too high
2211008 FM_VAK_KUBISCH_SP RV: cubic vacuum values faulty
2211009 FM_VAK_NICHT_KUBISCH_SP RV: non-cubic vacuum values faulty
2211010 FM_VAK_FHL_NR_UNBEK_SP RV: unknown vacuum error number
2211011
FM_CAN_MSG_ABWERFEN_SP
RV: Defective motor for rejecting
2211012
FM_TW_SP_PINOLE_GEZOGEN
Caution: Sleeve in extended
position, do not move placement
head!
2211013 FM_VAK_SEGM_UNDICHT_SP Leak in RV-head segment after
placement
2211015 FM_BZ_SCHUETZ_SZ4 Software enable relay defective
2211016 FM_BZ_DRUCKTLUFT Compressed air failure for too long
2211017 FM_BZ_UNBEK_ZUST Status unknown
2211018 FM_BZ_SCHUTZ Cover not correct
2211019 FM_BZ_HALTEPUNKT Break point not defined
2211020 FM_BZ_SCHLUESSEL Unknown key-switch message
2211021 FM_BZ_SENDENBZ Unknown message code to BZ
2211022 FM_BZ_HAUPTSCHUETZ Hardware defect (relay)
2211023 FM_GUI_TEXT_BB_ERR_WAR
TE_ENDE_PORT_KPF_REF
Gantry and head reference run
failed
2211024 FM_GUI_TEXT_BB_ERR_WAR
TE_ENDE_HOEHE_REF
Height reference run failed
2211025 FM_GUI_TEXT_BB_ERR_FAHR
E_POSITION
Unable to move gantry
2211027
FM_GUI_TEXT_TI_FOERD_FOLIE
Error upon cover foil of a tape
feeder
2211028 FM_BETR_DATEN_NOK Error upon producing operating data
for a HOST system
2211029 FM_HEAD_TIMEOUT Timeout during head functions
2211031 FM_NOZZLE_NOK Nozzle cannot be changed, function
not executed
2211039 FM_GEM_SPOOL_FULL Spoolfile is nearly full, machine
stopped (only if safespoolmode is
activ)
2211040 FM_REMOTE_START Remote Start by Gem-Host
2211041 FM_REMOTE_STOP Remote Stop by Gem-Host
SIPLACE GEM SW Version GEM 505.01 HOST Interface Manual
Page 228 of 236 ©Siemens AG, all rights reserved
SIPLACE Placement Head 3
CEID Name Description
2310001 Place3Cycle Placement cycle completed on head 3 and
<PLACEINFO3> , <PLACEINFO3SUB1> will be
updated.
33
2310002 PickUp3Cycle Pick-up cycle completed on 3 and
<PICKUPINFO3> will be updated.
42
2310003 Nozzle3changed <NOZZLECONF3> changed on placement-head 3. 35
2310004 RefRunHead3 Head <HEIGHTHEAD3> reference run complete
on head 3.
37
2310005 NozzleRefRun3 <NOZZLECONF3> length reference run complete
on head 3.
35
2310006 VacRefRun3 <VAKUUMDATAHEAD3> reference run complete
on head 3.
39
SIPLACE Placement Head 4
CEID Name Description
2410001 Place4Cycle Placement cycle completed on head 4 and
<PLACEINFO4>, <PLACEINFO4SUB1> will be
updated.
33
2410002 PickUp4Cycle Pick-up cycle completed on head 4 and
<PICKUPINFO4> will be updated.
43
2410003 Nozzle4changed <NOZZLECONF4> changed on placement-head 4. 36
2410004 RefRunHead4 Head <HEIGHTHEAD4> reference run complete
on head 4.
38
2410005 NozzleRefRun4 <NOZZLECONF4> length reference run complete
on head 4.
36
2410006 VacRefRun4 <VAKUUMDATAHEAD4> reference run complete
on head 4.
40
Traceability (only available if Traceability-Option is installed)
CEID Name Description
2510001 TraceData Traceabilitydata for one PCB 46
2510002 SpliceDetected Splicedetection at a Feeder (only if splicedetction
sensor is installed)
47
2510003 TraceOn Traceability activ 01
2510004 TraceOff Traceability inactiv 01
9 Alarms
There are no alarms defined for SIPLACE
SIPLACE GEM SW Version GEM 505.01
HOST Interface Manual
©Siemens AG, all rights reserved page 229 of 236
ALID ALCD ALTX Description ON CEID OFF
CEID
ALID Alarm ID
ALCD Alarm Severity Code. The low-order 7-bits of ALCD specifies the severity
code. The high-order bit (bit-8) shows the current alarm state (1=SET,
0=CLEAR).
ALTX Alarm Text. This is the actual string sent the Host in the Alarm Report
(S5F1).
ON CEID This is the Collection Event that is signaled when the alarm state changes
from CLEAR to SET ("going-on").
OFF CEID This is the Collection Event that is signaled when the alarm state changes
from SET to CLEAR ("going-off").
