MODEL GXH-3PH 0712-002 架台下 A UNDERFRAME A Fig. BA-4 200V 電源２ 200V Power Supply 2 396 . 398 . 399 396 . 398 . 399 396 . 398 . 399 396 . 398 . 399 396 . 398 . 399 395 397 382 391 . 392 384 385 387 386 386 . 388 381 . 383 3…
262 6301340012 BREAKER 2 Q201 845BA-100-362 4S230093
263 6301340029 EM-CONTACTOR 2 K33 845BA-100-363 4S210117
264 6301241586 COMP,CR 2 845BA-100-364 4F400025
265 6301340012 BREAKER 1 Q203 845BA-100-365 4S230093
266 6301340142 CIRCUIT PROTECTOR 1 Q204 845BA-100-366 4S250324
267 6300492194 EM-CONTACTOR 3 K28,K40,K50
845BA-100-367 4S210045
269 6300769166 COMP,CR 4 845BA-100-369 4F400008
270 6301612751 RAIL,WIRING 2 845BA-100-370 23N00105
271 6301340159 BREAKER 1 Q206 845BA-100-371 4S230094
272 6301340166 EM-CONTACTOR 1 K29 845BA-100-372 4S210118
274 6300911749 BRACKET,WIRING 8 845BA-100-374 23N10027
278 6301542607 TERMINAL(TB-BA1,TB-BC1) 1 845BA-100-378 4J320261
279 6301400747 TERMINAL 1 845BA-100-379 4J320241
286 4110435004 SCR PAN 4X8 6 845BA-100-856 221E0510
288 4111414008 WASHER V 4X9X0.8 6 845BA-100-858 221H0315
289 4110081706 WASHER SPR 4 6 845BA-100-859 221H0283
MODEL GXH-3PH
1004-004
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
BA-3
BA-3 list-1
MODEL GXH-3PH
0712-002
架台下
A UNDERFRAME A
Fig. BA-4
200V
電源２
200V Power Supply 2
396
.
398
.
399
396
.
398
.
399
396
.
398
.
399
396
.
398
.
399
396
.
398
.
399
395
397
382
391
.
392
384
385
387
386
386
.
388
381
.
383
367
367
365
.
366
364
.
369
368
.
369
371
.
369
368
.
369
365
.
366
370
370
370
370
364
.
369
372
373
.
374
.
375
376
See Fig.BA-2
Key No.161
See Fig.BA-2
Key No.166
BA-4 illust-1
364 6301705309 CIRCUIT PROTECTOR 2 Q221 845BA-100-464 4S250388
365 6301340074 ACCESSORY,WIRING 2 845BA-100-465 23N30652
366 6301340081 ACCESSORY,WIRING 2 845BA-100-466 23N30653
367 6301240824 RAIL,WIRING 2 845BA-100-467 23N00098
368 6301705316 CIRCUIT PROTECTOR 4 Q222,Q223 845BA-100-468 4S250389
369 6301340067 ACCESSORY,WIRING 6 845BA-100-469 23N30651
370 6300911749 BRACKET,WIRING 2 845BA-100-470 23N10027
371 6301340036 CIRCUIT PROTECTOR 1 Q205 845BA-100-471 4S250321
372 4080310004 VARISTOR R.A.V-781BXZ-4 1 F200 845BA-100-472 4V360007
373 6301231303 FUSE,SPECIAL 3 F201,F202,F203
845BA-100-473 4S300006
374 6301231310 FUSE HOLDER 3 845BA-100-474 4J200032
375 6301246338 CABLE JOINT,SLEEVE 12 845BA-100-475 4J310012
376 6301542584 TERMINAL(TB-BA2) 1 845BA-100-476 4J320259
381 6301254289 PROGRAM ROM 1 845BA-100-561 24000122
382 6301563244 P.C.B,MOUNT(UB63L) 1 U27 845BA-100-562 4B111582
383 6301493442 P.C.B,MOUNT 1 U05 845BA-100-563 4B111568
384 6301262864 FUSE HOLDER 1 845BA-100-564 4J200033
385 6301262871 ACCESSORY,WIRING 1 845BA-100-565 23N30605
386 6300911749 BRACKET,WIRING 2 845BA-100-566 23N10027
387 6300911688 ACCESSORY,WIRING 1 845BA-100-567 23N30497
388 4230252109 FUSE 250V 6.3A 1 F042 845BA-100-568 4S300023
391 6300137606 ACCESSORY,P.C.B 6 845BA-100-581 23L10024
392 6300137637 ACCESSORY,P.C.B 6 845BA-100-582 23L10025
395 4111130700 SCR PAN 3X16 6 845BA-100-852 221E0491
396 4110435004 SCR PAN 4X8 9 845BA-100-856 221E0510
397 4111132209 SCR PAN 4X16 6 845BA-100-857 221E0503
398 4111414008 WASHER V 4X9X0.8 9 845BA-100-858 221H0315
399 4110081706 WASHER SPR 4 9 845BA-100-859 221H0283
MODEL GXH-3PH
1004-004
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
BA-4
BA-4 list-1
