P-0273-004 - 第147页
1 6301579917 BOX(BL) 1 845BL-100-001 21 1B1302 3 6301564494 PLA TE 1 845BL-100-003 21 1DC829 51 6301552514 BRACKET 1 845BL-100-051 21 1FC121 52 6301562049 SUPPORT 1 845BL-100-052 21 1K3400 53 6301564487 PLA TE 1 845BL-10…
MODEL GXH-3PH
0712-002
3
51
53
55
54
52
1
M6×14
.
SW6
.
FW6
M6×14
.
SW6
.
FW6
64
65
66
M4×40 PAN
.
SW4 F
.
FW4 F
M5×8
.
SW5
.
FW5
M4-1 F
.
FW4 F
72
.
73
.
75
72
.
73
.
75
72
.
73
.
75
72
.
74
.
75
72
.
73
.
75
72
.
74
.
75
架台下電装
BOX
部 左
UNDERFRAME ELECTRICAL BOX
SECTION LEFT
Fig. BL-1
フレーム部
Frame Section
BL-1 illust-1
1 6301579917 BOX(BL) 1 845BL-100-001 211B1302
3 6301564494 PLATE 1 845BL-100-003 211DC829
51 6301552514 BRACKET 1 845BL-100-051 211FC121
52 6301562049 SUPPORT 1 845BL-100-052 211K3400
53 6301564487 PLATE 1 845BL-100-053 211DC828
54 6301587417 PLATE 1 845BL-100-054 211DD067
55 6301518428 SUPPORT 1 845BL-100-055 211K3315
64 6301600963 BRACKET 1 845BL-100-254 211FC884
65 6301405506 MOTOR,DC 1 M177 845BL-100-255 4M130026
66 6301399805 ACCESSORY,MOT-M 1 845BL-100-256 23M00062
72 6300007756 BOLT,HEX-SCT 18 M5X12 845BL-100-862 221A0030
73 6300010220 WASHER 14 BW5 845BL-100-863 221H0005
74 4110881702 WASHER V 5X10X1 4 845BL-100-864 221H0317
75 4111416705 WASHER SPR 5 18 845BL-100-865 221H0287
MODEL GXH-3PH
1004-004
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
BL-1
BL-1 list-1
MODEL GXH-3PH
0712-002
架台下電装
BOX
部 左
UNDERFRAME ELECTRICAL BOX
SECTION LEFT
Fig. BL-2
電装部
Electrical Section
169
192
.
193
.
195
185
.
187
.
188
182
.
183
181
.
184
.
183
186
.
187
185
.
187
.
188
185
.
187
.
188
185
.
187
.
188
181
.
184
.
183
191
190
151
152
156
157
158
161
162
164
163
173
177
174
172
171
172
189
.
187
166
175
176
.
180
153
BL-2 illust-1
