Error ID Item Description
130301 P.C.B. SUPPORT PINS THE DRIVER DATA WAS DETECTED OUTSIDE OF THE
UP/DOWN DATA POSSIBLE RANGE.
(Cause 1) The target value has exceeded the movable range of the device.
(Remedy 1) As the P.C.B. thickness has exceeded the specified value, set the data correctly.
130401 P.C.B. SUPPORT PINS LIMIT ERROR HAS BEEN DETECTED. ; BPH85 E/NR
UP/DOWN LIMIT
130402 P.C.B. SUPPORT PINS LIMIT ERROR HAS BEEN DETECTED. ; BHPH86 E/NR
UP/DOWN LIMIT
(Cause 1) Dirt adheres to the sensor and the optical beam is shielded.
(Cause 2) The sensor may be defective.
(Remedy 1) Wipe off dirt on the sensor and re-zero the support pin up/down mechanism.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
(Remedy 2) Contact our service personnel for details.
130601 P.C.B. SUPPORT PINS THE CONTROLLER CAN NOT RUN.
UP/DOWN COMMUNICATION
130602 P.C.B. SUPPORT PINS CONTROLLER INTERIOR IS OUT OF ORDER.
UP/DOWN COMMUNICATION
130603 P.C.B. SUPPORT PINS CONTROLLER IN COMMUNICATION ERROR CONDITION.
UP/DOWN COMMUNICATION
130604 P.C.B. SUPPORT PINS CONTROLLER INCOMPLETE RESULTING IN AN OVER
UP/DOWN COMMUNICATION TIME ALARM.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
140101
P.C.B. LOCATE LEVER ORIGIN
OUTPUT SIGNAL FROM THE PULSE MOTOR
DRIVER WAS NOT DETECTED.
140102
P.C.B. LOCATE LEVER ORIGIN
FEEDBACK VALUE IS INDEFINITE.
140103
P.C.B. LOCATE LEVER ORIGIN
THE P.C.B. LOCATE LEVER IS NOT AT ORIGIN.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0110-003 2-9 7 AFO01ETRP
3.3 Error IDs and Remedial Procedures
Error ID Item Description
140201 P.C.B. LOCATE LEVER TIMING TASK HAS NOT BEEN COMPLETED UNABLE TO
CONTINUE.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
140301 P.C.B. LOCATE LEVER DATA THE DRIVER DATA WAS DETECTED OUTSIDE OF THE
POSSIBLE RANGE.
(Cause 1) The target value has exceeded the movable range of the device.
(Remedy 1) As the P.C.B. thickness has exceeded the specified value, set the data correctly.
140401 P.C.B. LOCATE LEVER LIMIT LIMIT ERROR HAS BEEN DETECTED. ; BPH94 E/NR
140402 P.C.B. LOCATE LEVER LIMIT LIMIT ERROR HAS BEEN DETECTED. ; BPH95 E/NR
(Cause 1) Dirt adheres to the sensor and the optical beam is shielded.
(Cause 2) The sensor may be defective.
(Remedy 1) Wipe off dirt on the sensor and re-zero the support pin up/down mechanism.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
(Remedy 2) Contact our service personnel for details.
140601 P.C.B. LOCATE LEVER THE CONTROLLER CAN NOT RUN.
COMMUNICATION
140602 P.C.B. LOCATE LEVER CONTROLLER INTERIOR IS OUT OF ORDER.
COMMUNICATION
140603 P.C.B. LOCATE LEVER CONTROLLER IN COMMUNICATION ERROR CONDITION.
COMMUNICATION
140604 P.C.B. LOCATE LEVER CONTROLLER INCOMPLETE RESULTING IN AN OVERTIME
ALARM.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0207-004 2-98 AFO01ETRP
3.3 Error IDs and Remedial Procedures
Error ID Item Description
150601 L2 Conveyor Communication The controller can not run.
150602 L2 Conveyor Communication Controller interior is out of order.
150603 L2 Conveyor Communication Controller in communication error condition.
150604 L2 Conveyor Communication Controller incomplete resulting in an overtime alarm.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
160601 R2 Conveyor Communication The controller can not run.
160602 R2 Conveyor Communication Controller interior is out of order.
160603 R2 Conveyor Communication Controller in communication error condition.
160604 R2 Conveyor Communication Controller incomplete resulting in an overtime alarm.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
0207-001 2-98-1 AFO01ETRP
