Notes: (a) When the power is re-supplied without following the correct procedure
to cancel the error, the feeder installation error will be detected again
and the message will be issued because the contents of the feeder
installation error are backed up.
(b) No zeroing operation can be performed when a feeder installation error
is not canceled completely.
(1) Confirm that there is no error in the feeder installation sections.
(2) Select the object feeder and the direction of the movement. After that, press
the [ENABLE] button to move the feeder carriage to the position where the
error-caused feeder can be re-installed correctly.
Note: While the [ENABLE] button is held down, the feeder carriages keep on
moving.
(3) Check the cause of the error and re-install the feeder correctly.
(4) Press the [RETURN] button.
Ref.: The original window resumes.
(5) Zero all axes and re-start the operation.
0110-003 2-110 AFO01ETRP
Rear View (Upper Section)
Fig. 4B18-1 Location of Feeder Installation Error Sensors
3.3 Error IDs and Remedial Procedures
0301-005 2-111 AFO01ETRP
Error ID Item Description
430701 Linear Measure Linear measure alarm signal was detected.
430702 Linear Measure Communication error in linear measure system.
430703 Linear Measure Upper limit of linear measure data was out of range.
430704 Linear Measure Lower limit of linear measure data was out of range.
430705 Linear Measure Linear measure dirty signal was detected.
430706 Linear Measure Linear measure SYNC signal has been lost.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
430801 Cam-Positioner Cam-positioner alarm signal was detected.
(Cause 1) The cam positioner is abnormal.
(Remedy 1) Press the [RETURN] button to cancel the error display and contact our service
personnel for the remedy.
430901 Auto Recovery Cannot recover sequence.
430a01 Oil Cooler Oil cooler alarm signal was detected.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
430a02 Oil Cooler The oil cooler flowmeter alarm was detected.
(Cause 1) The cooling oil filter in the driving section of the main body may be defective.
(Remedy 1) Replace the oil filter with a new one.
Refer to “Cooling Oil Filter” in “1.3 Maintenance Spots” for the replacement
procedure.
430a03 Oil Cooler Oil cooler operation fails. See if pressure sensor works,
or breaker works, or power source incapable.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
3.3 Error IDs and Remedial Procedures
Error ID ltem Description
430b01 Cooling FAN Cooling FAN alarm signal was detected.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our ser-
vice personnel for the remedy.
430c01 Pickup Position Feedback Feedback value out of range. Please check feeder.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our ser-
vice personnel for the remedy.
430d01 Missing Large Comp. Fdr. Crg. is paused to avoid clash with missing component.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Before activating the feeder axis, shut off the load power and remove the mispicked
component.
Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service per-
sonnel for the remedy.
430e01 Air Cylinder Low pressure.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the air pressure and zero all axes. After that, re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
440101 Cam Phase Gap of cam phase has been detected.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0307-006 2-112 AFO01ETRP
3.3 Error IDs and Remedial Procedures
