0210-004 2 - 1 6 0 AFO01ETRP Error ID ltem Description 670601 Head Origin Offset T otal Designate Loop Exceeded T ime. (Cause 1) Each head deviated from its origin position in comparison with the master head. (Remedy 1) …
0110-003 2-159 AFO01ETRP
Error ID ltem Description
670301 Head Skip Communication Error
670302 Head Skip Head Origin
670303 Head Skip Overtime Head Origin Return
670304 Head Skip Unselected Nozzle Drop
670305 Head Skip Dummy Nozzle
670306 Head Skip Manual Bypass
670307 Head Skip Alarm Error
(Cause 1) Self-Diagnostics Error Message
(Cause 2) The voltage of the stabilization power supply unit (PSU) is abnormal.
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
(Remedy 2) Consult our service personnel for details.
670401 Nozzle Level Nozzle Level (Low) Was More Than Tolerance.
670402 Nozzle Level Nozzle Level (Low) Was Less Than Tolerance.
670403 Nozzle Level Nozzle Level (High) Was More Than Tolerance.
670404 Nozzle Level Nozzle Level (High) Was Less Than Tolerance.
(Cause 1) This error occurs when there is a big difference in nozzle levels in comparison with
the master nozzle during teaching operation.
(Remedy 1) Re-teach the data of the master nozzle.
670501 Master Head Offset Linear Measure System Was At High Position.
670502 Master Head Offset Linear Measure System Was At Low Position.
(Cause 1) The master nozzle or the linear measure detection sensor may not be attached
correctly.
(Remedy 1) Attach the master nozzle correctly.
It is required to adjust the linear measure detection sensor after it is attached
correctly.
3.3 Error IDs and Remedial Procedures
0210-004 2-160 AFO01ETRP
Error ID ltem Description
670601 Head Origin Offset Total Designate Loop Exceeded Time.
(Cause 1) Each head deviated from its origin position in comparison with the master head.
(Remedy 1) Check if the master head is not loose.
670701 Comp. Thickness Teach Component Thickness Was Less Than Tolerance.
670702 Comp. Thickness Teach Component Thickness Was More Than Tolerance.
(Cause 1) A mistake is found in the component thickness data of the component library data.
(Remedy 1) Set the component thickness data correctly.
670801 Recog. Data Teach Recognition Error Code.
670901 Trash Teach Trash Teach Error Code.
Note: Refer to “4. Troubleshooting on Recognition System” for details.
3.3 Error IDs and Remedial Procedures
0210-001 2-160-1 AFO01ETRP
3.3 Error IDs and Remedial Procedures
Error ID ltem Description
800101 Auto Noz. Bypass Started Nozzle down error(L)
800102 Auto Noz. Bypass Started Nozzle down error(H)
800103 Auto Noz. Bypass Started Handling err-cont:
800104 Auto Noz. Bypass Started Decreasing of comp.handling rate
800105 Auto Noz. Bypass Started Selected nozzle position error
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
800201 Auto Head Bypass Started Communication error.
800202 Auto Head Bypass Started Head origin error.
800203 Auto Head Bypass Started Overtime head origin error. Set ct:3(fixed value)
800204 Auto Head Bypass Started Unselected nozzle drop. Set ct:2(fixed value)
800205 Auto Head Bypass Started CAM position.
800206 Auto Head Bypass Started Origin Return Action.
800207 Auto Head Bypass Started Motor Out of Control
800208 Auto Head Bypass Started Current Overload.
800209 Auto Head Bypass Started Motor not connected.
800210 Auto Head Bypass Started Solenoid not connected.
800211 Auto Head Bypass Started Power line warning.
800212 Auto Head Bypass Started Power line error.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
