3.3 Error IDs and Remedial Procedures
0210-001 2-160-10 AFO01ETRP
Error ID ltem Description
80170a Teach Nozzle Bypass Nozzle Change Error.(Cam lock action)
80170b Teach Nozzle Bypass Nozzle Change Error.(Cam Free action)
80170c Teach Nozzle Bypass Cam Origin Error.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
801801 Teach Head Bypass Communication Error.
801802 Teach Head Bypass Head Origin Error.
801803 Teach Head Bypass Overtime Head Origin Return.
801804 Teach Head Bypass Unselected Nozzle Drop.
801805 Teach Head Bypass Dummy Nozzle.
801806 Teach Head Bypass Manual Bypass.
801807 Teach Head Bypass Alarm Error.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
801901 Nozzle Adjustment Nozzle up&down action is not available.
801902 Nozzle Adjustment Communication error.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
Error ID ltem Description
801a01 Warning Operation Product started by RUN MODE “PASS”Operation.
801a02 Warning Operation The P.C.B. before component placing was conveyed from X/Y
table.
801a03 Warning Operation The P.C.B. in the middle of component placing was conveyed
from X/Y table.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
801b01 Lightning Surge Warning Lightning Surge Protector works; Q204.
801b02 Lightning Surge Warning Lightning Surge Protector works; Q204. Running continue.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
801c01 Information This placement step was detected outside of the possible
range. This step is auto skip running.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
801c02 Information Feeder carriage has been paused to avoid clash with missing
component. Please collect component before operating the
feeder carriage.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Before activating the feeder axis, shut off the power and remove the mispicked
component.
Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
0307-002 2-160-11 AFO01ETRP
3.3 Error IDs and Remedial Procedures
3.3 Error IDs and Remedial Procedures
0307-003 2-160-12 AFO01ETRP
Error ID ltem Description
801c03 Information Data was changed during machine worked. The changed data
is not reflected in operation until it stops or interrupts opera-
tion.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
801d01 Semi-auto(continue) start mode Production operation was interrupted for the state where PCB
before component are placed exists on XY table.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
801e01 Placement Level Data Calculated data out of range. Please check library data and
pattern program data.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
801f01 Warm start mode auto change Operation was canceled for the state where the P.C.B. in the
middle of component placing is on X/Y table.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
809001 Internal Exception Notice CPU2 Vector 0 exception has been disregarded.
809002 Internal Exception Notice CPU2 spurious exception has been disregarded.
809003 Internal Exception Notice CPU2 undefined exception has been disregarded.
809004 Internal Exception Notice CPU3 undefined exception has been disregarded.
809005 Internal Exception Notice EB005 SYSFAIL exception has been disregarded.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
