4. T roubleshooting on Recognition System (Error ID) 4.1 T ypical Description T able 4B7 Recognition Error ID Item Description 02**1 1 1 1** Component Missing Component was not found. (Cause 1) The feeder carriage is loa…
3.3 Error IDs and Remedial Procedures
0307-003 2-160-12 AFO01ETRP
Error ID ltem Description
801c03 Information Data was changed during machine worked. The changed data
is not reflected in operation until it stops or interrupts opera-
tion.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
801d01 Semi-auto(continue) start mode Production operation was interrupted for the state where PCB
before component are placed exists on XY table.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
801e01 Placement Level Data Calculated data out of range. Please check library data and
pattern program data.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
801f01 Warm start mode auto change Operation was canceled for the state where the P.C.B. in the
middle of component placing is on X/Y table.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
809001 Internal Exception Notice CPU2 Vector 0 exception has been disregarded.
809002 Internal Exception Notice CPU2 spurious exception has been disregarded.
809003 Internal Exception Notice CPU2 undefined exception has been disregarded.
809004 Internal Exception Notice CPU3 undefined exception has been disregarded.
809005 Internal Exception Notice EB005 SYSFAIL exception has been disregarded.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Zero all axes and re-start the operation.
When the machine cannot be set to its normal condition, consult our service
personnel for the remedy.
4. Troubleshooting on Recognition System (Error ID)
4.1 Typical Description
Table 4B7
Recognition Error ID Item Description
02**1111** Component Missing Component was not found.
(Cause 1) The feeder carriage is loaded with a feeder that contains components dif-
ferent from the specified ones.
(Cause 2) The vacuum suction force is too weak.
(Cause 2) An improper nozzle is selected for the components or vice versa.
Mismatching parameters are set in the nozzle type data and the compo-
nent library data.
(Remedy 1) Check if proper components are used.
(Remedy 2) Check the vacuum pressure.
(Remedy 3) Check the parameters in the nozzle type data and the component library
data.
02 ******** Error in Outward Length Inspection Component Outward Length X is incorrect.
(Cause 1)
(Remedy 1)
(Continue to next page. )
*1 The recognition error IDs (IDs displayed in the “ERROR” window) are de-
scribed in the numerical order.
“*” will be filled with a numeric character.
*2 Described are the error name (item) and the description in the “ERROR”
window.
*3 Described are the causes and remedial procedures of the errors in “*2 (Item
and Description)”
The causes and remedies are correlated as follows.
(Cause 1) Æ (Remedy 1)
(Cause 2) Æ (Remedy 2)
(Cause 3) Æ (Remedy 3)
*4 This indicates that the related contents are described subsequently on the
next page.
0210-004 2-161
AFO01ETRP
*1
*2 *3
*2
*4
4. Troubleshooting on Recognition System (Error ID)
4.2 Recognition Error IDs and Controlled Areas
Basic System of Recognition Error IDs
A recognition error ID is expressed by 10 digits (decimal number) as
follows.
AA BB C DDDDD
Detailed Classification: Detail Code based on
Classification of Rec-
ognition Functions
Error Classification: Secondary Classifica-
tion Code of Detailed
Classification
Error Classification: Primary Classifica-
tion Code of Detailed
Classification
Classification of Recognition Functions
Classification of Recognition Functions
Table 4B8
Recognition Error IDs Classification of Recognition Functions
01 Recognition Communication and Data
Check
02 Component Recognition Function
03 P.E.C. Recognition Function
04 Nozzle Recognition Function
10 Various Teaching Functions
13 Broken Circuit of Lamp for Component Rec-
ognition
14 Lighting Control Board-to-Board Communi-
cation
4.2 Recognition Error IDs and Controlled Areas
