Recognition Error ID Item Description
0131300001 Error in “Camera POSITION X or POSITION Y” ----
Data.
0131300003 Error in “Camera ANGLE” Data. ----
0131300007 Error in “Camera 1 – 2 X or Y” Data. ----
0132300002 Error in “Camera GAIN or LEVEL” Data. ----
0133300001 Error in “Nozzle Offset High Mag. X or Y” Data. ----
0133300002 Error in “Nozzle Offset Low Mag. X or Y” Data. ----
0133300004 Error in “Nozzle O.D.Size” Data. ----
0133300005 Error in “Nozzle I.D.Size” Data. ----
0133300008 Error in “Nozzle V-Groove Size” Data. ----
0134300001 Error in “Indidual Nozzle Gain or Level” Data. ----
0135300001 Error in “Nozzle High or Low level offset” Data. ----
0136300001 Error in “Nozzle Position Offset” Data. ----
0137300001 Error in “Head Center X or Y Offset” Data. ----
(Cause) Wrong parameters are set.
(Remedy) Set correct parameters.
4.3 Recognition Error IDs and Remedial Procedures
0210-004 2-164 AFO01ETRP
Recognition Error ID Item Description
0138200000 Unavailable fiducial mark code was set. ----
0138200001 “Mark Size D2” is too big, compared with “D1”. ----
0138200002 “Mark Size D3” is too big, compared with “D1”. ----
0138200003 “Mark Size D2” is too big, comapred with“D3”. ----
0138200004 “Window Size” is smaller than “Mark Size”. ----
0138200005 “Mark Size D2” is not set. ----
0138200006 “Mark Size D3” is not set. ----
0138300001 Error in “P.C.B Recognition Mark Data Mark Size ----
D1 or D2 or D3” Data.
0138300003 Error in “P.C.B Recognition Mark Data Window ----
Size” Data.
(Cause) Wrong parameters are set for the P.E.C. recognition function.
(Remedy) Refer to “Section 2 Pattern Program” in “Vol. 3” for details and set correct
parameters.
4.3 Recognition Error IDs and Remedial Procedures
0210-004 2-165 AFO01ETRP
Recognition Error ID Item Description
0139211001 An improper parameter is specified as ----
“Component shape”.
0139211002 “Mold Size Tolerance X” is larger than “Mold ----
Size X”.
0139211003 “Mold Size Tolerance Y” is larger than “Mold ----
Size Y”.
0139211004 “Outward Length Tolerances” are larger than ----
“Outward Length”.
0139211005 A front reverse side judging cannot be carried out ----
by this component size or the lighting pattern.
0139212001 The total of “Corner 1 Dim X” and “Corner 4 Dim ----
X” is larger than “Mold Size X”.
0139212002 The total of “Corner 1 Dim Y” and “Corner 2 Dim ----
Y” is larger than “Mold Size Y”.
0139212003 The total of “Corner 2 Dim X” and “Corner 3 Dim ----
X” is larger than “Mold Size X”.
0139212004 The total of “Corner 3 Dim Y” and “Corner 4 Dim ----
Y” is larger than “Mold Size Y”.
0139212005 “Electrode Size” is larger than half of “Mold ----
Size X”.
0139213001 “# of Types” (lead data) is improper. ----
0139213002 “# of Groups” (lead data) is improper. ----
0139213003 The total of “# of Leads” (lead data) is too small. ----
0139213004 “No Detection” is set in all “Insp Condtn” text ----
boxes.
0139213005 “Lead Type No.” in “Lead Group 1” is improper. ----
0139213006 “Lead Type No.” in “Lead Group 2” is improper. ----
0139213007 “Lead Type No.” in “Lead Group 3” is improper. ----
0139213008 “Lead Type No.” in “Lead Group 4” is improper ----
0139213009 “Lead Type No.” in “Lead Group 5” is improper. ----
0139213010 “Lead Type No.” in “Lead Group 6” is improper. ----
(Cause) Wrong parameters are set.
(Remedy) Set correct parameters.
4.3 Recognition Error IDs and Remedial Procedures
0210-004 2-166 AFO01ETRP
