Recognition Error ID Item Description
02**3301** Error in Edge Detection Some edges cannot be detected because they
are hidden by the nozzle.
02**3302** Error in Edge Detection No Edge Detected.
02**3303** Error in Edge Detection Upper Edge Not Detected.
02**3304** Error in Edge Detection Left Edge Not Detected.
02**3305** Error in Edge Detection Lower Edge Not Detected.
02**3306** Error in Edge Detection Right Edge Not Detected.
(Cause 1) The selected component does not match the nozzle.
(Cause 2) Wrong parameters (edge data) are set for the selected component in the
component library data.
(Cause 3) The tapered part of the vacuum nozzle end or the diffusion plate is stained.
Fig. 4B23
(Remedy 1) Check the selected component and the vacuum nozzle.
Check if the feeder (B) offset data is correct.
(Remedy 2) Check the edge condition of the selected component and the compo-
nent library data.
If wrong parameters are set in the component library data, correct them.
(Remedy 3) Clean the vacuum nozzle end or the diffusion plate.
0210-004 2-184 AFO01ETRP
Component
Vacuum Nozzle
Dirty Spots
4.3 Recognition Error IDs and Remedial Procedures
Recognition Error ID Item Description
02**3401** Error in Line Detection Some linear edges cannot be detected because
they are hidden by the nozzle.
02**3402** Error in Line Detection No linear edge detected.
02**3403** Error in Line Detection The detected linear edge position does not match
the position data.
(Cause 1) There is a difference between the results of the line inspection of the se-
lected component and the component library data.
(Remedy 1) Check the line of the selected component and the component library
data. If wrong parameters are set in the component library data, correct
them.
02**3501** Error in Lead Detection Some leads cannot be detected because they
are hidden by the nozzle.
02**3502** Error in Lead Detection No Lead Detected.
02**3503** Error in Lead Detection Corner of Leads Not Detected.
02**3504** Error in Lead Detection Ends of Leads Not Detected.
02**3505** Error in Lead Detection Ends of Arrayed Leads Not Detected.
02**3506** Error in Lead Detection Lead Edges of Corner Not Detected.
02**3507** Error in Lead Detection Leads of Corner Not Detected.
02**3508** Error in Lead Detection The number of leads at the detected corner is
smaller than the set value.
02**3509** Error in Lead Detection Incorrect Lead-to-Lead Distance at Detected Cor-
ner.
02**3510** Error in Lead Detection Incorrect Lead-to-Lead Angle at Detected Cor-
ner.
(Cause 1) The results of the lead detection differ from the parameters specified in the
component library data for the selected components.
(Remedy 1) Check the leads of the selected component and the component library
data.
If wrong parameters are set in the component library data, correct them.
0210-004 2-185 AFO01ETRP
4.3 Recognition Error IDs and Remedial Procedures
0210-004 2-186 AFO01ETRP
4.3 Recognition Error IDs and Remedial Procedures
Recognition Error ID
Item Description
02**3512** Error in Lead Detection The detected number of leads is smaller than
the set value.
02**3513** Error in Lead Detection The detected number of leads is larger than the
set value.
02**3515** Error in Lead Detection The detected lead position does not match the
position data.
(Cause 1) The results of the lead detection differ from the parameters specified in the
component library data for the selected components.
(Remedy 1) Check the leads of the selected component and the component library
data.
If wrong parameters are set in the component library data, correct them.
02**3601** Error in Electrode(ball) Detection No Electrode(ball) Detected.
02**3602** Error in Electrode(ball) Detection Since a sufficient number of Electrode(ball) were
undetectable, it cannot position.
02**3603** Error in Electrode(ball) Detection There is Electrode(ball) undetectable in the line
or sequence of a group outside.
02**3604** Error in Electrode(ball) Detection Electrode(ball) which is in agreement with data
was undetectable.
02**3605** Error in Electrode(ball) Detection Electrode(ball) which is not specified was de-
tected.
(Cause 1) There is a difference between the results of the electrode (ball) inspection
of the selected component and the component library data.
(Remedy 1) Check the electrodes (balls) of the selected component and the compo-
nent library data.
Correct wrong parameters if they are set in the component library
data.
02**4101** Reverse Check Error The component is reversed.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Contact our service personnel for details.
