Recognition Error ID Item Description 02**4201** Error in Pick-up Position The pick-up position has deviated greatly in X Detection. direction. 02**4202** Error in Pick-up Position The pick-up position has deviated great…
0210-004 2-186 AFO01ETRP
4.3 Recognition Error IDs and Remedial Procedures
Recognition Error ID
Item Description
02**3512** Error in Lead Detection The detected number of leads is smaller than
the set value.
02**3513** Error in Lead Detection The detected number of leads is larger than the
set value.
02**3515** Error in Lead Detection The detected lead position does not match the
position data.
(Cause 1) The results of the lead detection differ from the parameters specified in the
component library data for the selected components.
(Remedy 1) Check the leads of the selected component and the component library
data.
If wrong parameters are set in the component library data, correct them.
02**3601** Error in Electrode(ball) Detection No Electrode(ball) Detected.
02**3602** Error in Electrode(ball) Detection Since a sufficient number of Electrode(ball) were
undetectable, it cannot position.
02**3603** Error in Electrode(ball) Detection There is Electrode(ball) undetectable in the line
or sequence of a group outside.
02**3604** Error in Electrode(ball) Detection Electrode(ball) which is in agreement with data
was undetectable.
02**3605** Error in Electrode(ball) Detection Electrode(ball) which is not specified was de-
tected.
(Cause 1) There is a difference between the results of the electrode (ball) inspection
of the selected component and the component library data.
(Remedy 1) Check the electrodes (balls) of the selected component and the compo-
nent library data.
Correct wrong parameters if they are set in the component library
data.
02**4101** Reverse Check Error The component is reversed.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Contact our service personnel for details.
Recognition Error ID Item Description
02**4201** Error in Pick-up Position The pick-up position has deviated greatly in X
Detection. direction.
02**4202** Error in Pick-up Position The pick-up position has deviated greatly in Y
Detection. direction.
02**4203** Error in Pick-up Position The pick angular skew is big.
Detection.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Contact our service personnel for details.
02**8001** Data Error Data Error in Process
02**8002** Data Error Error in Lighting Data
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Contact our service personnel for details.
02**9001** Other Errors Internal Processing Error
02**9002** Other Errors Impossible to set the detection window.
02**9003** Other Errors Impossible to set the window for arrayed lead end
detection.
02 **9004** Other Errors Impossible to set the window for lead detection at
the corner.
02**9005** Other Errors Impossible to set the window for lead detection.
02**9006** Other Errors Angle Calculation Impossible.
02**9007** Other Errors Internal Processing Error.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Contact our service personnel for details.
4.3 Recognition Error IDs and Remedial Procedures
0210-001 2-186-1 AFO01ETRP
4.3.3 P.E.C. Recognition Errors
AA BB C DDDDD
Detail Code
Secondary Error Classification (1 to 4)
Primary Error Classification (0 to 1)
Classification (03) of Recognition Functions
(a) Error IDs “*” will be filled with detail codes.
(b) When an error ID other than the described ones is issued,
contact our service personnel for some advice.
Table 4B12
Recognition Error ID Item Description
03001***** ---- Specified Mark Not Found in Recognizable
Range.
03002***** ---- Unstable Image around Fiducial Mark.
03003***** ---- Extensive Error in Similitude of Mark Shape.
03004***** ---- Extensive Error in Similitude of Mark Shape or
Size.
03011***** ---- Specified Mark Not Found in Recognizable
Range.
(Cause 1) The fiducial mark and the fiducial mark coordinates X and Y or the mark
data are not suitable.
(Remedy 1) Follow the steps below to reset the machine to the normal condition.
(1) When the [RETURN] button is pressed, the following recognition
window appears.
Fig. 4B24 Sample Display of Recognition Window
(Continue to the next page. )
0210-004 2-187 AFO01ETRP
