Recognition Error ID Item Description 1003013003 ---- Error in Camera Sensitivity (Front Lighting 2) Please adjust camera sensitivity . 1003013004 ---- Error in Instruction Object. The instruction object is not suitable.…
Recognition Error ID Item Description
1003011002 ---- Error in Lighting System (Back Lighting)
Failed in Teaching Operation for Assumed Bright-
ness.
(Cause 1) The lighting system may be abnormal.
(Remedy 1) Contact our service personnel for details.
1003011005 ---- Error in Lighting Intensity Data (Back Lighting)
The diffusion plate with which brightness differs
is attached.
(Cause 1) The lighting system may be abnormal.
(Remedy 1) Contact our service personnel for details.
1003012001 ---- Error in Lighting Intensity Data (Front Lighting 1)
The data has exceeded the specified range.
(Cause 1) The longevity of the lamp might have ended.
(Remedy 1) Replace the lamp with a new one.
Or, contact our service personnel for some advice.
1003012002 ---- Error in Lighting System (Front Lighting 1)
Failed in Teaching Operation for Assumed Bright-
ness.
(Cause 1) The lighting system may be abnormal.
(Remedy 1) Contact our service personnel for details.
1003013001 ----- Error in Lighting Intensity Data (Front Lighting 2)
The data has exceeded the specified range.
(Cause 1) The longevity of the lamp might have ended.
(Remedy 1) Replace the lamp with a new one.
Or, contact our service personnel for some advice.
1003013002 ---- Error in Lighting System (Front Lighting 2)
Failed in Teaching Operation for Assumed Bright-
ness.
(Cause 1) The lighting system may be abnormal.
(Remedy 1) Contact our service personnel for details.
0210-004 2-191 AFO01ETRP
4.3 Recognition Error IDs and Remedial Procedures
Recognition Error ID Item Description
1003013003 ---- Error in Camera Sensitivity (Front Lighting 2)
Please adjust camera sensitivity.
1003013004 ---- Error in Instruction Object.
The instruction object is not suitable.
(Cause 1) The lighting system may be abnormal.
(Remedy 1) Contact our service personnel for details.
0307-005 2-192 AFO01ETRP
4.3 Recognition Error IDs and Remedial Procedures
0210-001 2-192-1 AFO01ETRP
Recognition Error ID Item Description
10040***9* ---- Error in Teaching Data
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Perform the teaching operation again.
100401**01 ---- Component recognition camera dirt detection er-
ror. Dirt has been detected on recognition camera
lens or placement head lighting diffuser.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Wipe the cover glass or the diffusion plate with a soft cloth.
100401**02 ---- Component recognition camera dirt detection er-
ror. Abnormalities are in the lighting method, light-
ing intensity data, and gain level data.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the lighting mode, the lighting intensity, and the gain & level data.
100402**01 ---- Nozzle dirt detection error. Dirt has been detected
on pick-up nozzle or placement head lighting dif-
fuser.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Wipe the diffusion plate or the end and tapered area of the vacuum nozzle
with a soft cloth.
100402**02 ---- Nozzle dirt detection error. Abnormalities are in
the lighting method, lighting intensity data, and
gain level data.
(Cause 1) Self-Diagnostics Error Message
(Remedy 1) Check the lighting mode, the lighting intensity, and the gain & level data.
4.3 Recognition Error IDs and Remedial Procedures
