Carriage FES46
Feeder Holder
KLF-1309
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1
KLF-M3721-00 FRAME,L
1 /
Í
39
91312-06010 BOLT HEX.SOCKET HEAD
4
M6X10
2
KLF-M3721-50 FRAME,R
1
/
Í
40
91312-06012
BOLT HEX.SOCKET HEAD
30
M6X12
3
KLF-M3722-00 PANEL,CART L
1 /
Í
41
91312-08008 BOLT HEX.SOCKET HEAD
16
M8X8
4
KLF-M3722-50 PANEL,CART R
1 /
Í
42
91312-08012 BOLT HEX.SOCKET HEAD
12
M8X12
5
KLF-M3723-00 SPACER,ARM
2 /
Í
43
91312-08016 BOLT HEX.SOCKET HEAD
6
M8X16
6
KLF-M3724-00 COVER,CART L
1 /
Í
44
91312-08025 BOLT HEX.SOCKET HEAD
2
M8X25
7
KLF-M3724-50 COVER,CART R
1 /
Í
45
92902-06200 WASHER PLAIN
22
8
KLF-M3725-00 PLATE,CAM
2 /
Í
46
92902-08200 WASHER,PLAIN
16
9
KLF-M3726-00 TAPE
4
/
Í
47
95602-08100 NUT U
8
10
KLF-M3727-00
ARM,SUB L
1 /
Í
48
95302-08700 NUT HEXAGON
2
11
KLF-M3727-50 ARM,SUB R
1 /
Í
49
99480-04014 PIN,PARALLEL
4
12
KLF-M3728-00 PULL
2 /
Í
50
99480-06012 PIN,PARALLEL
4
13
KLF-M3729-A0 BASE,SUB ASSY.
1 /
Í
51
KLF-M373A-00 LABEL,BARCODE
1 /
Í
14
KLF-M3729-01 BASE
1 /
Í
52
KW3-M925L-00 LABEL,CONV.
1 /
15
KLF-M372A-00 CASTER
2 /
53 92012-04006 BOLT, BUTTON HEAD 8
16
KLF-M372B-00 CASTER
2 /
54
17
KLF-M372C-00 CHAIN
1 A
55
18
KLF-M372D-00 STEP SCREW
2 /
Í
56
19
KLF-M372E-00 RIB,L
1 /
Í
57
20
KLF-M372E-50 RIB,R
1
/
Í
58
21
KLF-M372G-00 CAM FOLLOWER
4 /
Í
59
22
KLF-M372H-00 RIB,L 2
1 /
Í
60
23
KLF-M372H-50 RIB,R 2
1 /
Í
61
24
KLF-M372J-00 BRACKET,BOLT
2 /
Í
62
25
KLF-M372K-00 COVER,ADJUST
2 /
Í
63
26
KLF-M372M-00 COVER,SUB ARM L
1 /
Í
64
27
KLF-M372M-50 COVER,SUB ARM R
1 /
Í
65
28
KLF-M372N-00 BRACKET,FIX L
1 /
Í
66
29
KLF-M372N-50 BRACKET,FIX R
1 /
Í
67
30
KKU-M1138-00 CAM FOLLOWER
4 /
Í
68
31
KL3-M1348-10 GAS SPRING
2 /
Í
69
32
90990-01J073 BOLT,HEX.SOCKET HEAD
2 70
33
90990-12J001 SCREW BIN.HEAD W/W
32 71
34
90990-41J047 COLLAR
2 72
35
90172-00J040 WASHER,EXTL.TOOTHED
1 73
36
90172-00J060 WASHER,EXTL.TOOTHED
22 74
37
91312-04006 BOLT HEX.SOCKET HEAD
1
M4X6
75
38
91312-04008 BOLT HEX.SOCKET HEAD
4
M4X8
76
3
5
Carriage FES46
Feeder Holder
KLF-1309
17
9
D
A
B
C
15
14
33
13
42
12
10
11
38
43
38
32
20
33
39
33
45
2
33
Type B, C
Type B, C
45
26
27
28
29
41
41
18
34
7
4
39
39
39
6
3
5
39
39
35
24
23
21
22
30
39
31
16
18
1
37
36
47
44
25
33
19
Type B, C
46
4
1
X-axis Motor / Sensor / Cover (4-Beam)
Moving-axis
