YSM40_mpl - 第46页
KLF-1309 Rev . :It had a change without the compatibility . Please be careful at the time of the parts ordering. Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。 No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Pa…
KLF-1309
3
14
16
18
2
11
12
13
13
10
15
7
6
9
19
4
17
14
8
5
1
22
21
20
23
24
6
3
Nozzle Changer (Base)
Nozzle
KLF-1309
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1
KLF-M9611-00 STAND
1 /
Í
39
2
KLF-M9612-00 PLATE
1
/
Í
40
3
KLF-M9614-00 PIN,JOINT
10 /
Í
41
4
KLF-M9615-00 PIN,GUIDE
2 /
Í
42
5
KLF-M9617-00 BLOCK,JOINT
1 /
Í
43
6
KLF-M961A-00 VALVE ASSY
1 /
Í
44
7
KLF-M961D-00 BLOCK
1 /
Í
45
8
KLF-M66M0-00 HNS,ANC DI
1
/
Í
46
9
$BF4-M3 JOINT
10
47
10
$FVU8-8
JOINT
1 48
11
$KM-10 MUFFLER
1 49
12
$SL8-01 JOINT
1 50
13
$ULA8 JOINT
1 51
14
90112-2AJ006 BOLT,HEX.SOCKET HEAD
4 52
15
91312-03020 BOLT,HEX.SOCKET HEAD
4
M3X20
53
16
91312-03030 BOLT,HEX.SOCKET HEAD
4
M3X30
54
17
91312-04012 BOLT,HEX.SOCKET HEAD
2
M4X12
55
18
91312-05010 BOLT HEX.SOCKET HEAD
2
M5X10
56
19
99480-04008 PIN,PARALLEL:4X8
2 57
20
$UB0425-R URETHANE TUBE
1
1200mm
58
21
$UB0425-BK
URETHANE TUBE
1
1200mm
59
22
$UB0850-R URETHANE TUBE
1
50mm
60
23
$ULAD8-6 JOINT
1 61
24
91312-06012 BOLT HEX.SOCKET HEAD
2 62
25 63
26 64
27 65
28 66
29 67
30 68
31 69
32 70
33 71
34 72
35 73
36 74
37 75
38 76
6
3
Nozzle Changer (Base)
Nozzle
KLF-1309
28
11
12
16
39
40
41
13
23
22
21
1
14
4
20
19
24
42
17
18
3
2
10
36
5
32
30
31
29
8
15
26
35
7
9
7
34
38
41
25
8
27
33
6
37
6
4
Nozzle Changer (HS)
Nozzle
