Frame Assy
Conveyor
KLF-1309
Rev. :It had a change without the compatibility. Please be careful at the time of the parts ordering.
Rev.: 過去に互換性の無い変更が入った部品。部品発注時は注意してください。
No. Part No. Part Name Q’ty Remarks Rev. Rank Level No. Part No. Part Name Q’ty Remarks Rev. Rank Level
1
KLF-M9121-02 FRAME,CONVEYOR 4
/
Í
39
2
KLF-M9130-A2 GUIDE SUB ASSY.
2
/
Í
40
3
KLF-M9130-B2 GUIDE SUB ASSY. 2
/
Í
41
4
KLF-M913A-A0 PULLEY,ASSY. 8
/
42
5
KGA-M9113-00 GUIDE 1,END 4
/
Í
43
6
KGA-M9114-00 GUIDE 2,END 4
/
Í
44
7
KGS-M9140-A0 PULLEY CONV. ASSY. 4
/
45
8
KGY-M9140-A0 PULLEY CONV. ASSY. 4
/
46
9
KLF-M9122-01 PLATE 1A,GUIDE 2
/
Í
47
10
KLF-M9122-11 PLATE 1A,GUIDE 2
/
Í
48
11
KLF-M9123-01 PLATE 2,GUIDE 4
/
Í
49
12
91312-03006 BOLT HEX.SOCKET HEAD 16 M3X6
50
13
91312-03008 BOLT HEX.SOCKET HEAD 20 M3X8
51
14
91312-04012 BOLT,HEX.SOCKET HEAD 8 M4X12
52
15
91312-05020 BOLT HEX.SOCKET HEAD 4 M5X20
53
16
92902-05200 WASHER PLAIN 20
54
17
92902-05600 WASHER PLAIN 16
55
18
95302-03700 NUT HEXAGON 48
56
19
KLF-M9120-A0 FRAME ASSY. 2
/
Í
57
20
KLF-M9120-B0 FRAME ASSY. 2
/
Í
58
21 59
22 60
23 61
24 62
25 63
26 64
27 65
28 66
29 67
30 68
31 69
32 70
33 71
34 72
35 73
36 74
37 75
38 76
7
5
Frame Assy
Conveyor
KLF-1309
