7 Converting the power supply on the HS-60 / D4 / D1/D2 machine Assembly Instructions, Converting the Power Supply
7.1 Tools and equipment 12/2013 Edition
228
7 Converting the power supply on the HS-60 / D4 / D1/
D2 machine
This section describes how to convert the power supply unit on the HS-60 placement machine in
order to adapt it to the supply networks in individual countries.
The motor circuit-breakers only need to be retrofitted on the HS-60 and D4. On the D1/D2 they
only have to be readjusted:
– Motor protection trip block: ZM-16-PKZ2; 00342495-xx
3 x 415 VAC ± 5%; 3 x 400 VAC ± 5%; 3 x 380 VAC ± 5%
– Motor protection trip block: ZM-32-PKZ2, USA option: 00342496-xx
3 x 230 VAC ± 5%; 3 x 208 VAC ± 5%
7.1 Tools and equipment
– Set of DIN 911 Allen keys
– Set of slotted-head screwdrivers
– Multimeter
7.2 Circuit diagrams
– Circuit diagram, 3 x 208 V~ conversion kit for SIPLACE HS-60
drawing no. 00119085-050101LD4, 2 sheets (see page 252
and 253)
– Circuit diagram, SIPLACE HS-60 conversion kit, international,
drawing no. 00119185-050101LD4, 2 sheets (see page 254
and 255)
Assembly Instructions, Converting the Power Supply 7 Converting the power supply on the HS-60 / D4 / D1/D2 machine
12/2013 Edition 7.3 Parts
229
7.3 Parts
7.3.1 Conversion kit, USA (3x208 VAC) for SIPLACE HF, item no. 00119605-02
The conversion kit consists of the following parts:
– ZM-32-PKZ2 motor protection trip block Item no.: 00342496-01
– HF cable: machine power supply (USA) Item no.: 00345937-01
– Teddy socket guard, 6310 series, white Item no.: 00357871-01
– Power supply conversion instructions
for SIPLACE HF/X/D/Di/MTC2/S-27HM/MTC/HS-60 Item no.: 00193437-xx
12/2013 Edition, German and English
7.3.2 SIPLACE HF conversion kit, international (3x400 VAC), item no.: 00119185-01
The conversion kit consists of the following parts:
– ZM-16-PKZ2 motor protection trip block Item no.:00342495-01
– Power supply conversion instructions
for SIPLACE HF/X/D/Di/MTC2/S-27HM/MTC/HS-60 Item no.: 00193437-xx
12/2013 Edition, German and English
7 Converting the power supply on the HS-60 / D4 / D1/D2 machine Assembly Instructions, Converting the Power Supply
7.4 Modules to be converted 12/2013 Edition
230
7.4 Modules to be converted
The following table lists those modules that have to be converted in order to adapt them to the
power supply network.
The connections for the station computer, LCD screens, uninterruptible power supply and compo-
nent tables need not be changed since they are connected to the placement machine's own 230
VAC system.
Module Sub-module Ratings
Power supply
00336145-xx
Transformer T1
00345634-xx
3 x 415 VAC ± 5%
3 x 400 VAC ± 5%
3 x 380 VAC ± 5%
3 x 230 VAC ± 5%
3 x 208 VAC ± 5%
Inrush current limiter
TG 31033-01
00341831-xx
3 x 415 VAC ± 5%
3 x 400 VAC ± 5%
3 x 380 VAC ± 5%
3 x 230 VAC ± 5%
3 x 208 VAC ± 5%
Motor protection trip block
ZM-16-PKZ2
00342495-xx
3 x 415 VAC ± 5%
3 x 400 VAC ± 5%
3 x 380 VAC ± 5%
Motor protection trip block
ZM-32-PKZ2, USA option
00342496-xx
3 x 230 VAC ± 5%
3 x 208 VAC ± 5%
BU1 service socket
Teddy socket guard,
6310 series, white,
00357871-01
1 x 115 VAC (USA)
Main power cable, 4 mm²
3 x 415 VAC ± 5%
3 x 400 VAC ± 5%
3 x 380 VAC ± 5%
Main power cable (USA), 6 mm²
00345937-xx
3 x 230 VAC ± 5%
3 x 208 VAC ± 5%
Tab. 7 - 1 Modules to be converted
