8 Converting the power supply on the HS-XX / Di machine using PKE32/XTU-32 Assembly Instructions, Converting the Power Supply
8.1 Tools and equipment 12/2013 Edition
256
8 Converting the power supply on the HS-XX / Di
machine using PKE32/XTU-32
This section describes how to convert the power supply units on HS-60 / D4 / D1/D2 placement
machines in order to adapt them to the supply networks in individual countries.
8.1 Tools and equipment
– Set of DIN 911 Allen keys
– Set of slotted-head screwdrivers
– Multimeter
8.2 Circuit diagrams
– Circuit diagram, 3 x 208 VAC conversion kit for SIPLACE HS-XX / D
drawing no. 00119801-010102LD4, 2 sheets (see page 275
and 276)
– Circuit diagram, 3 x 400 VAC conversion kit for SIPLACE HS-XX / D,
drawing no. 00119802-010101LD4, 2 sheets (see page 277
and 278)
8.3 Parts
8.3.1 3 x 208 VAC conversion kit for SIPLACE HS-60 / D1 / D2 / D4,
item no. 00119801-xx / all drawings
The conversion kit consists of the following parts:
– PKE32/XTU-32 motor protection switch Item no.: 03098183-01
– HS-60 cable: machine power supply (USA) Item no.: 00345937-01
– Teddy socket guard, 6310 series, white Item no.: 00357871-01
– Power supply conversion instructions
for SIPLACE HF/X/D/Di/MTC2/S-27HM/MTC/HS-60 Item no.: 00193437-xx
12/2013 Edition, German and English
8.3.2 SIPLACE HS-60 / D1 / D2 / D4 conversion kit, international (3x400 VAC),
item no.: 00119802-01 / all drawings
The conversion kit consists of the following parts:
– PKE32/XTU-32 motor protection switch Item no.:03098183-01
– Power supply conversion instructions
for SIPLACE HF/X/D/Di/MTC2/S-27HM/MTC/HS-60 Item no.: 00193437-xx
12/2013 Edition, German and English
Assembly Instructions, Converting the Power Supply 8 Converting the power supply on the HS-XX / Di machine using PKE32/XTU-32
12/2013 Edition 8.4 Modules to be converted
257
8.4 Modules to be converted
The following table lists those modules that have to be converted in order to adapt them to the
power supply network.
The connections for the station computer, LCD screens, uninterruptible power supply and compo-
nent tables need not be changed since they are connected to the placement machine's own
230 VAC system.
Module Sub-module Ratings
Power supply
00336145-xx (HS50)
00375318-xx (HS60)
03039393-xx (D1/D2)
03039618-xx (D4)
Transformer T1
00345634-xx (discontinued)
00374780-xx (HS50/60)
03039612-xx (D1/D2)
03039611-xx (D4)
3 x 415 VAC ± 5%
3 x 400 VAC ± 5%
3 x 380 VAC ± 5%
3 x 230 VAC ± 5%
3 x 208 VAC ± 5%
Inrush current limiter
00341831-xx (TG 31033-01)
3 x 415 VAC ± 5%
3 x 400 VAC ± 5%
3 x 380 VAC ± 5%
3 x 230 VAC ± 5%
3 x 208 VAC ± 5%
Motor protection switch
03098183-xx (PKE32/XTU-32)
3 x 415 VAC ± 5%
3 x 400 VAC ± 5%
3 x 380 VAC ± 5%
3 x 230 VAC ± 5%
3 x 208 VAC ± 5%
BU1 service socket
Teddy socket guard,
6310 series, white,
00357871-01
1 x 115 VAC (USA)
Main power cable, 4 mm²
3 x 415 VAC ± 5%
3 x 400 VAC ± 5%
3 x 380 VAC ± 5%
Main power cable (USA), 6 mm²
00345937-xx
3 x 230 VAC ± 5%
3 x 208 VAC ± 5%
Tab. 8 - 1 Modules to be converted
8 Converting the power supply on the HS-XX / Di machine using PKE32/XTU-32 Assembly Instructions, Converting the Power Supply
8.5 Converting the power supply from 3 x 400 VAC to 3 x 208 VAC 12/2013 Edition
258
8.5 Converting the power supply from 3 x 400 VAC to 3 x 208 VAC
RISK OF DEATH 8
Disconnect the machine correctly as described in section 1, page 145.
Disconnect the machine from the main power supply.
Take suitable action to ensure that the machine cannot be connected to the power supply dur-
ing the conversion work.
Put up warning signs to indicate that work is being carried out on the electrical system.
