4 Setting up and commissioning User manual SIPLACE X-Series 4.4 Setting up the placement machine Software Version SR.601.xx 11/2005 US E dition 190 4.4 Setting up the placeme nt machine 4.4.1 PCB transport height on the …

User manual SIPLACE X-Series 4 Setting up and commissioning

Software Version SR.601.xx 11/2005 US Edition 4.3 Infrastructure at the installation location

189

Fig. 4.3 - 5 Position of the board and connectors for the inrush current limitation

(1) Inrush current limitation board

X1, X2, X3 Connectors for configuring the inrush current limitation on the board

Æ Check the jumper assignment and correct if necessary.

3 x 380 VAC

3 x 400 VAC

3 x 415 VAC

3 x 208 VAC

3 x 230 VAC

4 Setting up and commissioning User manual SIPLACE X-Series

4.4 Setting up the placement machine Software Version SR.601.xx 11/2005 US Edition

190

4.4 Setting up the placement machine

4.4.1 PCB transport height on the machine

The machine can be set to the following PCB transport heights:

830 mm ± 15 mm Standard height 4

900 mm ± 15 mm SMEMA height 4

930 mm ± 15 mm SMEMA height 4

950 mm ± 15 mm SMEMA height 4

PLEASE NOTE 4

The PCB transport height is the distance between the top edge of the PCB conveyor belt and the

bottom edge of the machine feet.

4.4.2 Warning instructions

DANGER 4

Only SIEMENS engineers or qualified people are permitted to set up and commission the place-

ment machine.

Æ Always follow the applicable accident prevention regulations.

Æ Never lie beneath the machine in order to attach the machine feet. All the modules and parts

can be fitted from the spaces for the component feeder tables. If you nevertheless have to

carry out assembly work underneath the machine, then you must secure the machine by suit-

able means. The fork-lift must not be used as the only support.

Æ Make sure that the gantries are positioned over the PCB conveyor area so that you do not

restrict your head movement during assembly, thus excluding the risk of injury.

Æ Two people will be needed to adjust the height of the placement machine:

– one person to carry out the necessary assembly work,

– the other person to watch the raised machine during assembly and ensure that it does

not move.

Æ Wear special safety boots to protect your feet. Each machine foot weighs 6.75 kg.

User manual SIPLACE X-Series 4 Setting up and commissioning

Software Version SR.601.xx 11/2005 US Edition 4.4 Setting up the placement machine

191

4.4.3 Tools and equipment

You will need the following tools and equipment to adjust the height of your placement machine:

– Fork wrench, size 36, item no. 00096286-01

Size 36 for the adjusting screw M24x2x120 to adjust the height of the machine feet 4

– Hook wrench 135 - 145 for adjusting the middle machine feet

Item no. 00376519-xx 4

– Single-ended spanner, size 65, item no. 00353827-01

Size 65 for the hexagon lock nut M24 on the middle machine foot 4

– Allen key, size 10, item no. 00373926-01

for hexagon socket head screws M12x80 for fixing the spacers for the middle machine feet4

– Allen key, size 19, item no. 00373928-01

for hexagon socket head screw M24x90 for clamping the four outer machine feet clamps4

–Fork-lift

Fork length: min. 1800 mm 4

Carrying power: min. 6000 kg 4

Width between forks: see Fig. 4.4 - 1

– Spirit level : accuracy 0.02 mm/m

– Air cushion transport system: SIPLACE HSxx, item no. 00119002-xx
