PLEASE NOTE 5

Remove the component tape before a reference run.

Foil Jam Red Foil motor has locked up Leveling gears blocked by foil? => Remove

the foil

EEP-WriteErr

(Error while back-

ing up data in the

EEPROM)

Red The data back-up in the EE-

PROM was not carried out

correctly

Remove the component tape (tape can be

moved out by pressing the arrow keys or

pulled out after raising the pick-up window).

Press the SET button to confirm the error.

Then press the yellow button to confirm the

reference run prompt.

EEP-ReadErr

(Error while read-

ing the EEPROM)

Red Data was not read from the

EEPROM correctly

EEP-DataErr

(Error while back-

ing up the data in

the EEPROM)

Red The data back-up in the EE-

PROM was not carried out

fully

Reference o Red Position information is no

longer available for the com-

ponent tape drive

Remove the component tape (tape can be

moved out by pressing the arrow keys or

pulled out after raising the pick-up window).

Then press the "FOIL" button to start the

reference run.

CAN BusError Red CAN bus error Log off and on again, check the optical fiber

interface

ParNotSaved! Red Parameters were not saved Default parameters are loaded automatical-

ly, i.e. the most recent operator settings are

overwritten -> The settings (e.g. increment)

will have to be made again. Replace the

control board if this error occurs frequently.

ParWrongSave Red Wrong or incomplete param-

eters were saved

BootFlashErr

FlashDataErr

Red Can no longer write to boot

or application memory cor-

rectly

Replace the feeder module or control board

Text on the

LCD display

Status

display

Meaning Trouble-shooting

User manual SIPLACE X-Series 5 Tasks on the machine

Software Version SR.601.xx 11/2005 US Edition 5.7 Changing the set-up

271

5.7 Changing the set-up

5.7.1 Printing out the conversion instructions before changing the set-up

Before a change of set-up, print out the conversion instructions on the printer for the SIPLACE Pro

computer as described in the "SIPLACE Pro" manual or in the online help.

5.7.2 What you should note when changing the feeder modules

Handle the feeder modules carefully when you insert them into or remove them from the com-

ponent feeder table. Make sure that the X feeder modules do not bump against the centering

bar (see item 5 in Fig. 5.4 - 3

, page 260) on the component table.

Æ Vacuum the supporting surfaces of the feeder modules and clean the surface of the compo-

nent feeder table when necessary according to the instructions in the Preventive Mainte-

nance Manual.

Æ Remove loose components using a brush or a vacuum cleaner with a suitable nozzle.

5 Tasks on the machine User manual SIPLACE X-Series

5.8 Avoiding track errors Software Version SR.601.xx 11/2005 US Edition

272

5.8 Avoiding track errors

5.8.1 General

Æ Make sure that the areas around the feeder modules are clean and that there are no loose

components in the feeder area or under the feeder modules.

Æ Ensure that the supporting surfaces of the S feeder modules, and particularly the magnetic

rails of the component feeder tables, are clean and level.

Æ Refill promptly with components.

Æ Splice the tapes early. This generally means that you are to prepare the splicing material

when there is still approximately 1.5 m of tape on the reel.

Æ Handle the feeder modules carefully when you insert them into or remove them from the com-

ponent feeder table as these are high-precision devices.

Æ Close the flaps of the S feeder modules because they can be easily damaged when open.

Æ For X feeder modules, lower the pick-up window since it can easily be damaged when raised.

PLEASE NOTE 5

A raised pick-up window leads to noticeably impaired pick-up quality.

Æ Check that the pick-up position is set correctly for the components on the feeder modules.

Æ Check that the S feeder module connectors are plugged into the communication interface

correctly.

5.8.2 Avoiding track errors with the tape container

Æ Insert the separating plates correctly (see Fig. 5.3 - 4).

Æ Tape reels with a diameter of 15" (381 mm) or more should be stored on spindles.
