5 Tasks on the machine User manual SIPLAC E X-Series 5.11 Note operating status indicator lamp Software Version SR.601.xx 11/2005 US E dition 286
User manual SIPLACE X-Series 5 Tasks on the machine
Software Version SR.601.xx 11/2005 US Edition 5.11 Note operating status indicator lamp
285
unchanged flashes (7,7) unchanged Go to refill position
unchanged flashes (7,7) unchanged Transport being initialized
unchanged flashes (7,7) unchanged Place PCB in input conveyor
flashes (1,10) flashes (7,7) unchanged Remove PCB from output conveyor
unchanged flashes (7,7) flashes (1,10) Remove PCB from output conveyor 2
flashes (1,10) flashes (7,7) flashes (1,10) Width adjustment
unchanged flashes (1,10) unchanged Transport PCB
flashes (1,10) flashes (7,7) flashes (1,10) Both output conveyors are cleared
on flashes (1,10) on Transport error
on off on Go to service position
on Placement
flashes (1,20) Waiting for processing data
Error display
on off unchanged Machine error, right
on off unchanged Track empty, right
on off unchanged Nozzle configuration, right
on off unchanged Transport error, right
on off on Fiducial error, left and right
on off on Fiducial error, left and right
unchanged off on Track empty, left
unchanged off on Nozzle configuration, left
unchanged off on Transport error, left
unchanged off on Machine error, left
Pick-up error display
unchanged unchanged flashes (1,20)
First track empty, left
unchanged unchanged flashes (5,20)
Further tracks empty, left
unchanged unchanged flashes (5,5)
Penultimate track in use
unchanged unchanged flashes (1,2)
Last track in use, right
flashes (1,20) unchanged unchanged
First track empty, right
flashes (5,20) unchanged unchanged
Further tracks empty, right
flashes (5,5) unchanged unchanged
Penultimate track in use, right
flashes (1,2) unchanged unchanged
Last track in use, right
L1 (white)
(right lamp)
L2 (green) L3 (white)
(left lamp)
Meaning
5 Tasks on the machine User manual SIPLACE X-Series
5.11 Note operating status indicator lamp Software Version SR.601.xx 11/2005 US Edition
286
User manual SIPLACE X-Series 6 Component handling
Software Version SR.601.xx 11/2005 US Edition 6.1 X feeder modules for the component trolley from the SIPLACE X-series
287
6 Component handling
6.1 X feeder modules for the component trolley from
the SIPLACE X-series
A new generation of feeder modules has been developed for the X-series of placement machines.
Important features are the high precision of the pick-up position, online programmability, status
displays on an LCD display and easy handling when changing feeder modules during the place-
ment process. The power supply to the feeder modules is contactless and uses an inductive in-
terface on the component trolley docking unit. Each feeder module communicates with the feeder
module control unit (FCU) on the component trolley docking unit via two optoelectronic channels
(optical fiber). The feeder module control unit is, in turn, connected to the machine's control unit
via the CAN bus.
6.1.1 Tape feeder modules for the SIPLACE X-series
6.1.1.1 Tape material
The possible tape widths range from 8 mm to 88 mm. The tape material is blister or paper. Com-
ponent tapes with a permanently adhesive cover foil (PSA foil) can also be processed. This will
require the "PSA Kit" option.
The design of the tape feeder modules was based on the following tape standards:
DIN EN 60286-3 (12/1998) / IEC 60286-3 (12/1997)
JIS C 0806-3 (1999)
ANSI/EIA 481-C (10/2003) 6
The overall height of the blister tapes depends on the tape width, and must not exceed the follow-
ing maximum values:
Tape width Overall height of the blister tapes
8 mm Max. 3.5 mm
12 mm Max. 6.5 mm
16 mm and wider Max. 25 mm
