3 Technical data User manual SIPLACE X-Series 3.2 Performance dat a for the mac hines Software Version S R.601.xx 11/2005 US Edition 98 *) The HF-ser ies component trolleys and feeder m odules cannot be used together wit…
User manual SIPLACE X-Series 3 Technical data
Software Version SR.601.xx 11/2005 US Edition 3.2 Performance data for the machines
97
3
3
C&P12 C&P12 28,000 comp./h
C&P12 C&P6 23,300 comp./h
C&P12 TH 17,700 comp./h
C&P6 C&P6 18,600 comp./h
C&P6 TH 13,000 comp./h
TH TH 7,400 comp./h
Placement
positions
3,500 / gantry
Component
range
0.6 x 0.3 mm² (0201*) to 85 x 85 mm² / 125 x 10 mm²,
up to 200 x 125 mm² (with restrictions)
*) Smaller components, e.g. 01005, available on request
Component
height
C&P20: 4 mm
C&P12: 6 mm
C&P6: 8.5 mm
TH: 25 mm (larger heights available on request)
Placement
accuracy
C&P20
C&P12
C&P12
C&P6
TH
TH
± 41 µm (3 σ), ± 55 µm (4 σ)
± 45 µm (3 σ), ± 60 µm (4 σ)
± 41 µm (3 σ), ± 55 µm (4 σ)
± 45 µm (3 σ), ± 60 µm (4 σ)
± 26 µm (3 σ), ± 35 µm (4 σ)
± 22 µm (3 σ), ± 30 µm (4 σ)
CO camera, type 23 (6 x 6)
CO camera, type 28 (18 x 18)
CO camera, type 29 (27 x 27)
CO camera, type 29 (27 x 27)
CO camera, type 33 (55 x 45)
CO camera, type 25 (16 x 16)
Angular
accuracy
C&P20
C&P12
C&P12
C&P6
TH
TH
± 0.5° (3 σ), ± 0.7° (4 σ)
± 0.5° (3 σ), ± 0.7° (4 σ)
± 0.5° (3 σ), ± 0.7° (4 σ)
± 0.2° (3 σ), ± 0.3° (4 σ)
± 0.05° (3 σ), ± 0.07° (4 σ)
± 0.05° (3 σ), ± 0.07° (4 σ)
CO camera, type 23 (6 x 6)
CO camera, type 28 (18 x 18)
CO camera, type 29 (27 x 27)
CO camera, type 29 (27 x 27)
CO camera, type 33 (55 x 45)
CO camera, type 25 (16 x 16)
Component
feeding
(component
trolley X-series)
4 component trolleys with tape reel holders and integral waste containers
40 x 8 mm X feeder module locations per component trolley or matrix tray
changers in place of component trolleys
SIPLACE X2: 2 MTC
SIPLACE X3: 1 MTC
Feeder module
types (X-series)
Component tapes, waffle-pack trays
3 Technical data User manual SIPLACE X-Series
3.2 Performance data for the machines Software Version SR.601.xx 11/2005 US Edition
98
*) The HF-series component trolleys and feeder modules cannot be used together with the 20-nozzle
Collect & Place head.
3
Feeding capacity
(component
trolley X-series)
160 tracks Width: 8 mm 8 mm X feeder modules
80 tracks Width: 12 mm 12 mm X feeder modules
64 tracks Width: 16 mm 16 mm X feeder modules
64 tracks Width: 24 mm 24 mm X feeder modules
40 tracks Width: 32 mm 32 mm X feeder modules
32 tracks Width: 44 mm 44 mm X feeder modules
24 tracks Width: 56 mm 56 mm X feeder modules
20 tracks Width: 72 mm 72 mm X feeder modules
16 tracks Width: 88 mm 88 mm X feeder modules
Component
feeding
(component
trolley HF-series)
4 component trolleys with tape reel holders and integral waste containers
15 x 30 mm wide locations per component trolley or matrix tray changers
in place of component trolleys:
SIPLACE X2: 2 MTC
SIPLACE X3: 1 MTC
Feeder module
types (HF series)
Tapes, bulk cases, stick magazines, application-specific OEM feeder
modules, surftape feeder modules (8, 12, 16 mm), waffle-pack trays
Feeding capacity
(component
trolley
HF-series *)
180 tracks Width: 8 mm 60 S feeder modules, 3 x 8 mm
120 tracks Width: 8 mm 60 S feeder modules, 2 x 8 mm
60 tracks Width: 12 or 16 mm 60 S feeder modules, 12/16 mm
40 tracks Width: 24 or 32 mm 40 S feeder modules, 24/32 mm
28 tracks Width: 44 mm 28 S feeder modules, 44 mm
24 tracks Width: 56 mm 24 S feeder modules, 56 mm
20 tracks Width: 72 mm 20 S feeder modules, 72 mm
16 tracks Width: 88 mm 16 S feeder modules, 88 mm
PCB format
(LxW)
Single conveyor
50 x 50 mm² to 450 x 508 mm²
50 x 80 mm² to 610 x 508 mm² ("Long board" option)
Dual conveyor
50 x 50 mm² to 450 x 250 mm²
50 x 80 mm² to 610 x 250 mm² ("Long board" option)
Dual conveyor in Single conveyor mode
50 x 50 mm² to 450 x 450 mm²
50 x 80 mm² to 610 x 450 mm² ("Long board" option)
PCB thickness 0.3 to 4.5 mm (thicker PCBs available on request)
User manual SIPLACE X-Series 3 Technical data
Software Version SR.601.xx 11/2005 US Edition 3.3 Ratings of the placement system
99
3.3 Ratings of the placement system
3
Electrical ratings
Supply voltage 3 x 208 VAC ± 5 %; 50/60 Hz (for the U.S.A. version)
3 x 230 VAC ± 5 %; 50/60 Hz
3 x 380 VAC ± 5 %; 50/60 Hz
3 x 400 VAC ± 5 %; 50/60 Hz (Europe)
3 x 415 VAC ± 5 %; 50/60 Hz
Fuses 3 x 32 A (3 x 208 VAC)
3 x 32 A (3 x 230 VAC)
3 x 16 A (3 x 380 VAC)
3 x 16 A (3 x 400 VAC)
3 x 16 A (3 x 415 VAC)
Nominal apparent power 4.7 kVA (SIPLACE X4)
4.1 kVA (SIPLACE X3)
3.3 kVA (SIPLACE X2)
Rated current consumption 11.3 A / 3 x 400 VAC (SIPLACE X4)
9.7 A / 3 x 400 VAC (SIPLACE X3)
8.1 A / 3 x 400 VAC (SIPLACE X2)
Power failure max. 20 msec
Compressed air supply
Compressed air pressure
p
min
p
max
0.5 MPa = 5.0 bar
1.0 MPa = 10 bar
Compressed air connection 3/4" thread with 1/2" hose connection
Compressed air consumption
with 4 tape cutters and in
relation to the placement head
configuration
SIPLACE X4
4 x C&P20 990 st. l/min
4 x C&P12 or 4 x C&P6 950 st. l/min
SIPLACE X3
3 x C&P12 or 3 x C&P6 750 st. l/min
2 x C&P12/TH or 2 x C&P6/TH 600 st. l/min
SIPLACE X2
C&P12/TH or C&P6/TH 350 st. l/min
C&P12/C&P12 or C&P6/C&P6 450 st. l/min
TH / TH 300 st. l/min
Operating pressure 0.48 MPa ± 0.025 MPa (4.8 bar ± 0.25 bar)
Compressed air specification
Maximum particle size by density, based on ISO/DIS 8573-1 (class 1)
Particle size 0.1 µm
