SITEST SITEST Overview 603 Overview SITEST S tude nt Guide Advanced Level 1 SIPLACE D-Series EN 05/2007 SITEST 9-3 9.1.2 SITEST Overview 603 As you can see in the overvie w diagram, the calibration menus in the SITEST so…
SITEST
Overview SITEST Starting/Terminating the Test Program
Student Guide Advanced Level 1 SIPLACE D-Series
SITEST EN 05/2007
9-2
X The main view of the user interface of the test program will appear on the screen shortly afterwards.
9.1.1.2 Terminating the Program
There are three ways of properly terminating the test program, i.e. either
Via the
Mode
menu and the menu item Exit,
or via the
ESC
button or by proceeding as follows:
X In the main view, click on the .
9-1: Starting SITEST.
X Confirm this message with
YES
.
NOTE:
The
ESC
button is the only option which closes SITEST from every window.
NOTE:
If newly determined or edited machine data have not been saved yet, an appropriate message
will be displayed before exiting the program prompting you to save the data (see example
below).
X Click on
YES
to save the data and exit
SITEST or click on
No
if you do not want to
save the data. The following dialog will be
shown:
X Click on
YES
. SITEST will be closed.
SITEST
SITEST Overview 603 Overview SITEST
Student Guide Advanced Level 1 SIPLACE D-Series
EN 05/2007 SITEST
9-3
9.1.2 SITEST Overview 603
As you can see in the overview diagram, the calibration menus in the SITEST software are allocated to
the hardware components on which each is fitted or for which the function is used.
SITEST
Overview SITEST Overview of Calibration Tools
Student Guide Advanced Level 1 SIPLACE D-Series
SITEST EN 05/2007
9-4
9.1.3 Overview of Calibration Tools
9.1.4 Overview of Settings and Calibration Work
The settings and calibration work have been sorted in the same order and assigned to the service work
listed.
adjust - and
calibration tools
adjust and
calibration jobs
Machine types
(without S15/F3)
Digital Manometer 00311487 -01
Digital Manometer with analouge-cable for
S15/F3 00313523 -01
Track signal tester for S/F 00322510-02
Adapter cable track signal tester f. F5HM/S27HM
00360395-01
Track signal tester for HS/HF 00343785-01
glueing gauge for incremental scale exchange.
gaugge for 0.8mm plate distance (Trace out
magnet 00358519-01)
Belt tension meter TSM 00326015-01
Axis test box Vers.6 00303430-06 alternatively to
SAT
SIPLACE Axis Tester SAT 03002801-01
Adapter board for A364 Axis controller
03051220.xx
RC-Filter 02102858-01
0,2mm distance gauge 00325445-01 from gauge
set 00327005-01
Star-0-point.gauge 00326164-01 from gauge set
00327005-01
power supply for Star mounting DLM-heads
00353277-01
1.0 mm pin (replace 1.3mm pin from gauge set
00327005-01)
1,4; 1,5; 1,6mm pins from gauge set 00327005-
01
gauge Z-axis stop top 00331308-01
Test connector safety loop coplan ILD 2000
00337304-01
calibration tool coplan 00315365-03
calibration tool Vision Version II (clear) 00316308
-
03
calibration tool Vision Version 3 (for hf / white)
03010565-01
calibration nozzle D-zero-point-corr. Twin
03008862-02
I/O-Tester for SXX/FX 00321960-01
wiring test adapter 14 pole 02304826-01
wiring test adapter 34 pole 02304827-01
adjust gauge for clamping new TSP
S27/HS60/HF specific
adjust gauge for clamping sensor new TSP
S27/HS60/HF specific
gauge f. Z-Axis bearing C&P (* special trained
staff only) 335346
gauge for ball race(* special trained staff only)
333625
Mapping plate S/F/HS single TSP 00325743-01
Mapping plate S/F/HS DoubleTSP 00325698-01
Mapping plate HF single or double TSP 00355064-
01
Fine calibration set 00343710-01
exchange vacuum distrib./Star/
air kiss unit. All
S15
F3
exchange incremental encoder
gantry
All
S/F
F5HM/S
27HM
HF/
HS
exchange incremental scale
gantry
All
S/F
F5HM/S
27HM
HF/
HS
Exchange incremental scale
gantry X-Axis HF / X
HF/
HS
wit ho ut
gauge
Exchange incremental scale
gantry X-Axis D1 / D2
HF/
HS
at
mom.
wit ho ut
gauge
Exchange incremental scale
gantry Y-Axis HS / D4
HF/
HS
HS-
ver s .
Exchange incremental scale
gantry Y-Axis HF / X
HF/
HS
HF-
ver s .
Exchange incremental scale
gantry Y-Axis D1/D2
HF/
HS
D1-
ver s .
replacement Y-Magnets
HS/HF/X/D series
all with
lin. drive
exchange 'head board' C&P
head
exchange 'conversion board
large axis'
exchange incremental encoder
DP axis All All
exchange lightbarrier bottom
C&P head All
exchange placement star All
All with
DLM x
exchange Z-motor All All All All
exchange Z-belt All All All All All
exchange Z-top stop All
exchange drive belt /- motor All All All All
exchange coplanarity module All F All F
exchange PCB camera X/ D
All
without
. HF
exchange C&P-placement
head X/ D
All
without
. HF
exchange component cameras
All
without
. HF
exchange segment Twin-head X/D HF HF
Display I/O-States of the I/O-
Boards
All
S/F
wiring test ribbon cable All All
exchange ballrace only spec.
trained staff All All
Mapping
S/F/
HS
S/F/
HS
Mapping
HF
Fine calibration
All
All S/F
without
S27/F5
HM
The measuring in 1.3 mm is replaced by a 1.1 mm version The Allen key 14 mm 00373927-01 is t o adjust machine SMEMA height The Allen key 19 mm 00373928-01 is to fix MA-feets
