3.4.10.2 Single Conveyor Construction
3-26: PCB conveyor construction (D4)
Legend
The single conveyor system consists of an input conveyor, two placement areas, the intermediate
conveyor and the output conveyor. Each conveyor has automatic width adjustment and two lifting tables
to clamp the PCB in place.
1 Input conveyor 5 Output conveyor
2 Processing conveyor 1 6 Lifting table 1
3 Intermediate conveyor 7 Lifting table 2
4 Processing conveyor 2 8 Conveyor vat
Overview
Conveyor System Assemblies
Student Guide Advanced Level 1 SIPLACE D-Series
EN 05/2007 Overview
3-35
3.4.10.3 Dual Conveyor Construction
3-27: Dual conveyor construction (D4)
Legend
The dual conveyor has two conveyor lanes (1 and 2). In the standard model, the fixed conveyor side is
on the right side of each lane. This fixed conveyor side can be easily changed to the left.
1 Input conveyor 5 Processing conveyor 2
2 Processing conveyor 1 6 Lifting table 2
3 Lifting table 1 7 Output conveyor
4 Intermediate conveyor 8 Conveyor vat
