平成 25 年 6 月初版発行 Published, Jun. 2013 CHIP MOUNTING SYSTEM 立体分解図 EXPLODED ILLUSTRA TION 編集及び発行所 Editing & Publishing Printed by T .H.I 不許複製 1306-001 奥付 COLOPHON

Key No. PART No. PART NAME Q’ty

REMARKS

NOTE

C01 0949A045 UNIT_I/O 1 1101501003-001

C02 1015B000 BRACKET 1 1101501003-002

C03 221AA016 ROHS_HEX-SCT 2 1101501003-003

C11 09490054 ASSY_TAG 1 1101501003-011

C11 -01 0949A043 EQUIPMENT 1 3094900054-001

C11 -02 0949A018 CORD 2 3094900054-002

C11 -03 0949A017 CORD 1 3094900054-003

C11 -04 0949A00Y CORD 1 3094900054-004

C11 -06 4J300015 CAB_JOINTTERMIN 1 3094900054-006

C11 -07 4J300050 CAB_JOINTTERMIN 3 3094900054-007

C11 -08 23N20115 TUBE_WIRING 4 3094900054-008

C11 -09 23N20103 TUBE_WIRING 4 3094900054-009

C11 -10 0914B30E PLUGGABLE_FUSE 1 3094900054-010

C11 -11 0914B30F TERMINAL 1 3094900054-011

C11 -12 0914B30G END_PLATE 1 3094900054-012

C11 -13 0949A01R NAME_PLATE 1 3094900054-013

C11 -14 23N30524 ACCESS_WIRING 1 3094900054-014

C11 -15 4V320007 FUSE 250V 1A 1 3094900054-015

C11 -16 23N30737 ACCESS_WIRING(M 2 3094900054-016

C12 23N10027 BRACKET_WIRING 2 1101501003-012

C13 23N30542 DIN_RAIL 1 1101501003-013

C14 0949A044 TAG_CTL 1 1101501003-014

C16 0916D209 ACCESS_WIRING(M 20 1101501003-016

C17 0916D60A ACCESS_WIRING(M 10 1101501003-017

C18 221DA053 MACHINE_SCREW 3 1101501003-018

Fig. N1-10

Fig. N1

1306-001

GS-DA620

MEMO
