ASM_Nozzles_EN
Components and Nozzles Job Guide Edition 04/2020 EN www.asm-smt.com
Components and Nozzles
Job Guide
Edition 04/2020 EN
www.asm-smt.com
All names identified by ® are registered trademarks of ASM Assembly Systems GmbH & Co. KG. The remaining trademarks in this
publication may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.
We have reviewed the contents of this publication to ensure consistency with the hardware and software described. Since variance
cannot be precluded entirely, we cannot guarantee full consistency. However, the information in this publication is reviewed regularly
and any necessary corrections are included in subsequent editions.
Copyright © ASM Assembly Systems Technical data subject to change
ASM Assembly Systems GmbH & Co. KG
Rupert-Mayer-Strasse 44
81379 Munich
Germany
Item no.: 00196645-04
www.asm-smt.com Printed by ASM Assembly Systems
Table of Contents
www.asm-smt.com
1 Introduction: General Information about Components, Nozzles and Adapters
2 2-Pin Components and Standard Nozzles
3 SOT/TO Components and Standard Nozzles
4 SO Components and Standard Nozzles
5 PLCC/SOJ Components and Standard Nozzles
6 QFP Components and Standard Nozzles
7 Various Components and Standard Nozzles
