Measuring nozzles for the SIPLACE MeasuringFeederX
1403 (ceramic)
L = 9.800 mm
Tip: 0.900 x 0.500 mm (LxW)
Item no. 03206822
1404 (ceramic)
L = 9.400 mm
Tip: 1.700 x 1.200 mm (LxW)
Item no. 03206823
1406 (ceramic)
L = 10.400 mm
Tip: 0.450 x 0.350 mm (LxW)
Item no. 03013303
2403 (ceramic)
L = 16.000 mm
Tip: 0.900 x 0.500 mm (LxW)
Item no. 03206825
2404 (ceramic)
L = 15.000 mm
Tip: 1.700 x 1.200 mm (LxW)
Item no. 03206826
2406 (ceramic)
L = 16.500 mm
Tip: 0.450 x 0.350 mm (LxW)
Item no. 03206827
1 - 37
www.asm-smt.com
Measuring nozzles for the SIPLACE MeasuringFeederX
4403 / 6403 (ceramic)
L = 10.800 mm
Tip: 0.900 x 0.500 mm (LxW)
Item no. 03206822
4404 / 6404 (ceramic)
L = 9.400 mm
Tip: 1.700 x 1.200 mm (LxW)
Item no. 03206823
4406 / 6406 (ceramic)
L = 11.000 mm
Tip: 0.450 x 0.350 mm (LxW)
Item no. 03013303
The following measuring nozzle sets are available:
– Item no. 03212453
Measuring nozzle 10xx set (each with 2x 1403, 2x 1404, 2x 1406)
– Item no. 03212452
Measuring nozzle 20xx set (each with 2x 2403, 2x 2404, 2x 2406)
– Item no. 03212454
Measuring nozzle 40xx/60xx set (each with 2x 4403, 2x 4404, 2x 4406)
