2 - 2-Pin Components and Standard Nozzles
2 - 1
www.asm-smt.com
2 pin components C&P20A/M CPP C&P20P/M2/P2 Twin Head
Component shape
[LxWxH (mm)]
CS
file
Nozzle types
0201m resistor
Silicon body
[0.25*0.125*0.09]
80
0201m resistor
Ceramic body
[0.25*0.125*0.09]
81
0201m capacitor
[0.25*0.125*0.125]
83
0201m inductor
[0.25*0.125*0.200]
84
03015m resistor
Silicon body
[0.3*0.15*0.1]
85
03015m resistor
Ceramic body
[0.3*0.15*0.1]
86
2 - 2
www.asm-smt.com
01005 (0402m) res-
istor
[0.39x0.19x0.12]
96
01005 (0402m) capa-
citor
[0.36x0.18x0.18]
97
0201 (0603m) resistor
[0.6x0.3x0.25]
98
0201 (0603m) capacit-
ors
[0.6x0.3x0.3]
99
0402
[1.0x0.5x0.35]
100
0402
[1.0x0.5x0.5]
101
2 - 3
