Mini-MELF Diode SOD 80 [3.4x1.6x1.6] 203 MELF Small Diode Thick SOD 87 [3.6x2.0x2.0] 204 Maxi-MELF Diode / LL-41 [5.0x2.8x2.7] 205 2 - 7 www.asm-smt.com

2 pin components C&P20A/M CPP C&P20P/M2/P2 Twin Head

Component shape

[LxWxH (mm)]

file

Nozzle types

Ceramic Resonator

[7.0x2.8x2.8]

1200

Micro-Melf

[2.0x1.2x1.2]

200

Mini-MELF

[3.5x1.4x1.4]

201

Maxi-MELF

[5.9x2.2x2.2]

202

2 - 6

www.asm-smt.com

Mini-MELF

Diode SOD 80

[3.4x1.6x1.6]

203

MELF Small Diode

Thick SOD 87

[3.6x2.0x2.0]

204

Maxi-MELF

Diode / LL-41

[5.0x2.8x2.7]

205

2 - 7

www.asm-smt.com

2 pin components C&P20A/M CPP C&P20P/M2/P2 Twin Head

Component shape

[LxWxH (mm)]

file

Nozzle types

TANTAL

3.2x1.6 A

[3.2x1.6x1.8]

300

TANTAL

3.4x2.8 B

[3.5x2.8x2.1]

301

TANTAL

5.8x3.2 C

[6.0x3.2x2.8]

302
