5 - PLCC/SOJ Components and Standard Nozzles 5 - 1 www.asm-smt.com
SO components C&P20A/M CPP C&P20P/M2/P2 Twin Head
Component shape
[LxWxH (mm)]
CS
file
Nozzle types
SSOP 38
[12.6x7.8x1.8]
661
SSOP 44
[17.9x10.3x2.515]
663
SSOP 48
[15.88x10.31x2.59]
664
SSOP 56
[18.4x10.35x2.6]
665
SSOP 64
[26.3x14.25x2.1]
666
4 - 12
www.asm-smt.com
5 - PLCC/SOJ Components and Standard Nozzles
5 - 1
www.asm-smt.com
PLCC/SOJ components C&P20A/M CPP C&P20P/M2/P2 Twin Head
Component shape
[LxWxH (mm)]
CS
file
Nozzle types
PLCC 20
[9.85x9.85x4.35]
700
PLCC 28
[12.35x12.35x4.35]
701
5 - 2
