29
OM-1646
1005-001
14.1 Outline of Maintenance
14.1.2 Preparation for Maintenance
14.1.2.1 Preparation for Cleaning
Prepare the following items.
•
Brush
Use a brush whose bristles do not come off if possible.
•
Rag
Use a rag made of such material as cotton, etc., that produces as less waste
thread as possible.
A clean rag must be used depending on a spot to be cleaned.
Notice
The remaining waste thread if any will cause the machine to break down.
•
Oiled Rag
Use a rag made of such material as cotton, etc., that produces as less waste
thread as possible.
Too much grease should not be applied and any different type of grease should
not be mixed into the specied one.
Notice
The remaining waste thread if any will cause the machine to break down.
•
Gloves
Use the gloves made of material (such as rubber) which leaves bers as less as
possible.
Notice
The remaining waste thread if any will cause the machine to break down.
•
Vacuum Cleaner
If the suction hole the Vacuum cleaner is changed to a smaller one, some spots
can be cleaned more easily.
30
OM-1646
1005-001
14.1 Outline of Maintenance
14.1.2.2 Preparation for Lubrication
Prepare for the specied types of grease and lubrication tools.
SpeciedGreases
•
DAPHNE EPONEX GREASE No. 1 (IDEMITSU KOSAN)
•
MOLYNOC GREASE
AP1 (NIPPON OIL CORPORATION)
•
BARRIERTA IEL/V (NOK Klueber CO.,Ltd.)
Note
Before lubrication, wipe off old grease. Otherwise, the effect of grease and oil
will decrease.
Same Types of Lubricants
•
Grease Types equivalent to DAPHNE EPONEX GREASE No. 1 (IDEMITSU
KOSAN)
Grease Names Makers
Alvania Grease No. 1 Showa Shell Sekiyu K.K
Multinoc Grease 1 NIPPON OIL CORPORATION
Jomo Lisonix Grease No. 1 JAPAN ENERGY CORPORATION
Dynamax No. 1 COSMO OIL LUBRICANTS
Lithtan 1 ESSO OIL
MP Grease No. 1 KYGNUS
Gemico MP-1 Tonen General Sekiyu K.K
Multemp PS1 KYODOH YUSHI CO., LTD.
T1
•
Grease Types equivalent to MOLYNOC GREASE AP1 (NIPPON OIL
CORPORATION)
Grease Names Makers
DAPHINE Grease M No. 1 Idemitsu Kosan Co., Ltd.
Jomo Lisonix Grease M No. 1 JAPAN ENERGY CORPORATION
COSMO MOLYBDEN GREASE
No. 1
COSMO OIL LUBRICANTS
BEACON Q2 ESSO OIL
Gemico MD2 Tonen General Sekiyu K.K
M5 GREASE 1 KYGNUS
T2
31
OM-1646
1005-001
14.1 Outline of Maintenance
Speciedlubricationtools
(1) Brush
Use a brush whose bristles do not come off if possible.
Notice
Do not use a brush for ball screws and splines.
(2) Vinyl Gloves
Use a pair of vinyl gloves to apply grease or oil by hand.
(3) Hand Grease Gun
Standard : KH-120
Part No. : 22
8A022
Maker
: Yamada Corporation
Note
Use this gun only for DAPHNE EPONEX GREASE No. 1.
Reference
Refer to the attached instruction manuals for the hand grease gun for the
usage.
F28
•
Attachment for Hand Grease Gun KH-120
Standard Shape Part No. Remarks
Type H
216M0439 THK
SPK-3C
228A0021
Yamada
Corporation
T3
Note
It is not attached to the machine. Purchase it separately if necessary.
