The Machine >> Sensor Positions MEC-CP842-1.0E 3-21 3.3.10 T ape Cutter (ST1) X04E X04D C746M1019 C746M1T1 1 X04D X04E TAPE CUTTER UPPER LIMIT TAPE CUTTER LOWER LIMIT Sensor No. SIGNAL NAME
The Machine >> Sensor Positions
3-20 MEC-CP842-1.0E
3.3.9 Tape Feeder Unit (ST1, 2)
X03C
X03B
X036
C746M1018
C746M1T10
X036
X03B
X03C
X03D
ST2 LARGE PART CHECK
FEEDING FORWARD LIMIT
FEEDING RETRACT LIMIT
TAPE END CHECK
Sensor No.
SIGNAL NAME
The Machine >> Sensor Positions
MEC-CP842-1.0E 3-21
3.3.10 Tape Cutter (ST1)
X04E
X04D
C746M1019
C746M1T11
X04D
X04E
TAPE CUTTER UPPER LIMIT
TAPE CUTTER LOWER LIMIT
Sensor No.
SIGNAL NAME
The Machine >> Sensor Positions
3-22 MEC-CP842-1.0E
3.3.11 Nozzle Clutch (ST10)
X039
X04F
X03A
C746M1020
C746M1T12
X039
X03A
X04F
ST10 NOZZLE CLUTCH ORIGIN POSITION
ST10 NOZZLE CLUTCH ENGAGEMENT CHECK
ST11 HEAD A CHECK
Sensor No.
SIGNAL NAME
