Maintena nce >> Cleaning 5-10 MEC-CP842-1.0E 5.1.8 Machine Interior (Weekly) Point Chip parts and other foreign objects will accu mulate in the machine during operation. Such objects should be removed from the ma c…

Maintenance >> Cleaning

MEC-CP842-1.0E 5-9

Next remove the filter case and clean the filter element.

4 Disconnect the drain hose from the regulator if one is used.

5 Remove the filter case by rotating it while pressing the lock down.

6 Remove any drainage collected in the filter case and wash the case with neutral

detergent.

7 Remove and clean the element.

Note: The element should be replaced every 2 years.

Assemble the filter regulator after cleaning, attach the air-hose, and open the valve

lever.

C746M3008

Filter regulator

AW3000-02-BD

Mist separator

AFM3000-02-D

O-ring

Lock knob Lock knob

Filter case

Model : 111585

Manufacturer : SMC

Filter element

Model : 630617

Manufacturer : SMC

Element assemby

Maintenance >> Cleaning

5-10 MEC-CP842-1.0E

5.1.8 Machine Interior (Weekly)

Point

Chip parts and other foreign objects will accumulate in the machine during operation.

Such objects should be removed from the machine to keep the machine in good work-

ing order.

Procedure

1 Use a vacuum cleaner to remove the foreign objects from the machine interior.

2 Use a dry cloth to wipe grease off of all areas that do not require lubrication.

Caution:Do not use an air blower to clean the machine interior because dust or small objects may be

blown into and damage other areas of the machine.

WARNING

Turn the main power off before performing this procedure.

Maintenance >> Cleaning

MEC-CP842-1.0E 5-11

5.1.9 Part Height Check Sensor Lens (Weekly)

Point

The lenses should be cleaned periodically to ensure accuracy during part height and

nozzle length measurement.

Procedure

Use a soft brush (such as those used to clean camera lenses) to clean the sensor lens.

If the lens is excessively dirty, then use a commercially available lens cleaner.

WARNING

Be sure to turn the main power off before performing this proce-

dure.

C746M3011

Sensor lens
