Maintenance >> Cleaning
5-16 MEC-CP842-1.0E
5.1.14 Carrier Rodless Cylinder (Monthly)
Point
Scattered chips, dust, and fine fibers adhere to the slide surface of the rodless cylinder
used to drive the carrier. As a result, it is necessary to perform periodic cleaning.
Procedure
1 Lightly wipe the slide surface of the rodless cylinder using a fine cloth. Remove
any dirt etc. that has accumulated between the ends of the slider surface and
the absorber holder.
2 Apply some grease to a fine cloth and wipe along the slider surface.
Note: Use Daphne Eponex No. 2 grease.
WARNING
Turn the main power off before performing this procedure.
C746M3013
Carrier cylinder
Absorber holder
Slider
Slide surface
Absorber holder
Maintenance >> Cleaning
MEC-CP842-1.0E 5-17
5.1.15 Nozzle Filter (Every 3 Months)
Point
The filter inside the shaft becomes dirty during the course of machine operation, and
should be replaced approximately every 3 months. If errors occur frequently for a spe-
cific nozzle, it is probable that the flow of air is being impeded by a dirty filter.
Procedure
1 Squeeze in the levers shown in the figure below, and carefully extract the filter.
Caution:
1. Do not apply excess force to the nozzle shaft.
2. Ensure that the filter is returned to the nozzle with the levers at the bottom.
2 Remove the pin from the filter assembly and replace both the filter and pin.
WARNING
Turn the main power off before performing this procedure.
C746M301
5
Filter Assy
C746M301
4
Pin
Filter
Maintenance >> Cleaning
5-18 MEC-CP842-1.0E
5.1.16 Cleaning Checklist
C746M3T01Ea
CheckScheduleCleaning points
1
Every 8 Hours
2
Monthly
3
Every 8 Hours
4
Every 8 Hours
5
Every 8 Hours
6
Every 3 Months
7
Weekly
8
Weekly
9
Weekly
10
Monthly
Monthly
11
Weekly
12
Monthly
13
14
Monthly
Nozzle Interior
Fluorescent Nozzle Stickers
Waste Tape Box and Filter
Waste Tape Duct
Reject Parts Box
Nozzle Filter
Camera Glass
Filter Regulator
Machine Interior
Tapered Clutch on the Nozzle Indexing Shaft
Part Height Check Sensor Lens
Air Filter
Oil Cooler Air Filter
Carrier Rodless Cylinder
Removing Parts from the Camera Glass
15
Weekly
