CM101-D (Mechanical 20170704) - 第22页
1-E 本体部 Mai n B ody パーツレイアウト Kit No. キット品 番 Kit N am e キット名称 N610043208AA ｾｸｼｮﾝN o. PARTS LAYOUT Section No. - - M9 ( KN610043208AA-17-5 )
Ref
No.
Remarks
R
1
Q'ty
1-D
本体部
Main Body
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610043208AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
BRACKET
1
1 KXFB03RQA00
DUCT
1
2 N210061148AC
DUCT
1
3 N210061149AC
COVER
1
4 N210069808AC
COVER
1
5 N210069809AB
BRACKET
1
6 N210069810AA
SCREW
4
8 N510018307AA
Cross recessed Truss head machine screw M6X12-4.8 A2S (Trivalent)
SPACER
2
9 N510028399AA BSF-6130E
BRACKET
2
10 N210084015AA
BRACKET
1
11 N210084017AB
DUCT
1
12 N210084019AA
DUCT
1
13 N210084020AA
SPACER
2
14 N510027910AA BSF-6120E
BOLT
4
15 N510017356AA
Hexagon socket head cap screw M4X20-10.9 A2J (Trivalent) Full thread
PLATE
1
16 N210086362AA
BOLT
4
17 N510019211AA EH0508 Trivalent chromate
M8
--
( KN610043208AA-17-4 )
1-E
本体部
Main Body
パーツレイアウト
Kit No.
キット品
番
Kit Name
キット名称
N610043208AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
M9
( KN610043208AA-17-5 )
Ref
No.
Remarks
R
1
Q'ty
1-E
本体部
Main Body
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610043208AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
BRACKET
1
1 N210065297AC
BRACKET
1
2 N210065298AB
BRACKET
1
3 N210069823AB
BRACKET
1
4 N210061168AB
BRACKET
1
5 N210069815AA
PLUG
2
6 KXF02CRAA00 KQP-06
FAN-GUARD
1
7 KXFP007AA00 109-620
FAN-GUARD
1
8 KXF07S8AA00 109-619E
PUMP
1
9 N510062045AA
S
KHA400-317-G1-KG558
GAUGE
1
10 KXF0E1H0A00 GZ46-K-02
JOINT
1
11 N431KQVD-044 KQVD10-03S
REGULATOR
1
12 N510025329AA AR20-02BG-1RY-X2251
REGULATOR
1
13 N510025330AA AR20-02BG-RY-X2251
JOINT
1
14 KXF02CZAA00 KQR06-10
JOINT
1
15 KXF09MKAA00 KQE06-02
GROMMET
1
16 KXF0DT7AA00 B-19-2
SWITCH
1
17 N510010256AA ISE30-C4H-25-MB
REGULATOR
1
18 N510059943AA ARP30-02-RY-X2120
SPACER
2
19 N510059944AA BSB-635E
SPACER
4
20 N510025347AA BSB-545E
FAN
1
21 N610029791AA
S
REGULATOR
1
22 KXF073KAA00 ARP3000-02
GAUGE
1
23 N439G36201 G36-2-01
REGULATOR
1
24 N510024039AA
REGULATOR
1
25 N510024039AA
BRACKET
1
26 N210084018AA
SWITCH
1
27 N510061333AA ISE30A-C4H-N-MBY
M10
--
( KN610043208AA-17-5 )
