1-F 本体部 Mai n B ody パーツレイアウト Kit No. キット品 番 Kit N am e キット名称 N610043208AA ｾｸｼｮﾝN o. PARTS LAYOUT Section No. - - M11 ( KN610043208AA-17-6 )
Ref
No.
Remarks
R
1
Q'ty
1-E
本体部
Main Body
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610043208AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
BRACKET
1
1 N210065297AC
BRACKET
1
2 N210065298AB
BRACKET
1
3 N210069823AB
BRACKET
1
4 N210061168AB
BRACKET
1
5 N210069815AA
PLUG
2
6 KXF02CRAA00 KQP-06
FAN-GUARD
1
7 KXFP007AA00 109-620
FAN-GUARD
1
8 KXF07S8AA00 109-619E
PUMP
1
9 N510062045AA
S
KHA400-317-G1-KG558
GAUGE
1
10 KXF0E1H0A00 GZ46-K-02
JOINT
1
11 N431KQVD-044 KQVD10-03S
REGULATOR
1
12 N510025329AA AR20-02BG-1RY-X2251
REGULATOR
1
13 N510025330AA AR20-02BG-RY-X2251
JOINT
1
14 KXF02CZAA00 KQR06-10
JOINT
1
15 KXF09MKAA00 KQE06-02
GROMMET
1
16 KXF0DT7AA00 B-19-2
SWITCH
1
17 N510010256AA ISE30-C4H-25-MB
REGULATOR
1
18 N510059943AA ARP30-02-RY-X2120
SPACER
2
19 N510059944AA BSB-635E
SPACER
4
20 N510025347AA BSB-545E
FAN
1
21 N610029791AA
S
REGULATOR
1
22 KXF073KAA00 ARP3000-02
GAUGE
1
23 N439G36201 G36-2-01
REGULATOR
1
24 N510024039AA
REGULATOR
1
25 N510024039AA
BRACKET
1
26 N210084018AA
SWITCH
1
27 N510061333AA ISE30A-C4H-N-MBY
M10
--
( KN610043208AA-17-5 )
1-F
本体部
Main Body
パーツレイアウト
Kit No.
キット品
番
Kit Name
キット名称
N610043208AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
M11
( KN610043208AA-17-6 )
Ref
No.
Remarks
R
1
Q'ty
1-F
本体部
Main Body
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610043208AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
PLATE
1
1 N210061143AC
COVER
1
2 N210069801AB
COVER
1
3 N210069800AB
COVER
1
4 N210076552AB
BRACKET
1
5 N210077377AA
BRACKET
1
6 N210077449AA
PW106A1
6
7 KXFB02RKA00
COVER
1
8 N210070633AB
COVER
1
9 N210070634AB
COVER
1
10 N210076553AB
BRACKET
1
11 N210090569AA
CAP
4
12 KXF0DLPAA01 CP-328-B-6 hole process ivory(DDA)
BOLT
4
13 N510017645AA
Hexagon socket Flat head bolt M6X12-10.9 A2J (Trivalent)
SCREW
12
14 N510018036AA
Cross recessed Pan head machine screw M3X10-4.8 A2J (Trivalent)
SPACER
4
16 N510029481AA ASF-4140E
SCREW
4
17 N510018367AA
Hexagon socket set screw Cup point M4X16-45H A2J (Trivalent)
SENSOR(250mm)
3
18 N610002221AA
S
SPACER
6
19 N210053167AB
BRACKET
1
20 N210078388AA
COVER
1
21 N210077548AA
COVER
2
22 N210078206AA
BRACKET
4
23 N210052551AA
COVER
1
24 N210106341AA
SCREW
4
25 N510018303AA
Cross recessed Truss head machine screw M5X8-4.8 A2S(Trivalent)
M12
--
( KN610043208AA-17-6 )
