Repair and Repla cement Procedures ProM aster 25 00 User Manua l 7-43 Figure 7-30 Carriag e Assemb ly
Repair and Replacement Procedures
7-42 ProMaster 2500 User Manual
Item
No.
Part
Number Description Quantity
1 250-0125-004 #6 spacer, .140” i.d., .250” o.d. 12
2 220-0113-002 Screw, 4–40 x 3/8”, cap head 6
3 234-0009-002 #2 flat washer, .096” i.d., .250” o.d. 4
4 220-0207-002 Screw, 6–32 x 3/8”, cap head 2
5 265-0030-625 Dowel pin, 1/8” d x 5/8” l 4
6 220-0005-911 Screw, 2–56 x 3/8, cap head 4
7 210-5624-901 Hex nut, 5/16–24, 1/2” flts, 1/4” t 2
8 210-0640-901 Hex nut, 3/8–16, 9/16” flts, 7/16” t 2
9 280-0018-901 Needle bearing, 1/8” i.d, 1/4” o.d.,
1/4” l
14
10 280-0014-904 Roller bearing, 1/4” i.d., 1/2” o.d.,
.1875” t
4
11 284-2290-901 Input valve 2
12 234-0015-906 Washer, .265” i.d., .505” o.d., .062” t 2
13 290-1836-901 Bushing, 1/8 i.d., 3/16” o.d., 5/16” l 4
14 287-5500-902 Air cylinder, .47” o.d., 3/8” bore 2
15 284-5530-901 Flow valve 2
16 604-0058-001 Test site clamp 2
17 604-0059-001 Test site pivot 2
18 604-0060-001 Test site plunger 2
19 614-0021-001 Test site base 1
20 617-0019-001 Programmer clamp 1
21 665-0008-001 Test site pivot shaft 6
22 641-0025-001 Test site plunger shaft 2
24 815-1989-001 Microswitch actuator assembly 2
27 665-0007-001 Test site clamp shaft 2
Repair and Replacement Procedures
ProMaster 2500 User Manual 7-43
Figure 7-30
Carriage Assembly
Repair and Replacement Procedures
7-44 ProMaster 2500 User Manual
Item
No. Part Number Description Quantity
1 249-0316-901 O-ring 2
2 220-1375-221 Screw, 10-24 x 3/8, socket head 4
3 220-0113-002 Screw, 4-40 x 3/8, cap head 5
4 220-0412-911 Screw, 10-24 x 1/2, cap head 2
5 234-0004-901 #4 flat washer, .125” i.d., .281” o.d. 5
6 622-1305-001 Cable clamp 1
7 234-0002-901 #6 flat washer, .156” i.d., .375” o.d. 4
9 220-0317-921 Screw, 8-32 x 1/4, button head 6
11 220-0100-331 Screw, 4-40 x 1/8, cup 1
12 280-0014-904 Roller bearing, 1/4 “ i.d., 1/2” o.d.,
.1875 t
4
13 280-0034-901 Linear bearing, 3/4” i.d., 1.625” o.d.,
1.625” t
2
14 210-4375-902 Anti-backlash nut 1
15 604-0055-001 Carriage body 1
16 604-0057-001 Carriage tracking block 1
17 636-0071-001 Beam position plate 1
18 641-0026-001 Optic flag 1
21 251-1350-901 Spacer, 1/4” i.d., 3/8” o.d., 1/16 l 4
22 815-1991-001 Pulse collector optic assembly 1
