Computer Remote Control

E-2 ProMaster 2500 User Manual

Handler Computer Remote Control

This section lists commands that specifically affect the device handling

functions of the 2500. It includes the following information:

•

Handler Remote Command Set

— Lists the available handler CRC

commands. A command summary, which lists commands,

descriptions, and the 2500’s response, precedes the complete list.

•

Handler Remote Error Codes

— Lists the handler error codes that

may be returned while the 2500 is being operated in computer remote

mode.

System Setup

The 2500 handler and labeler controllers receive CRC commands and

send responses to the host computer through the RS-232C port labeled

“Remote RS232” on the back of the 2500. This is the only port that will

respond to the handler or labeler CRC commands listed in this section.

To ensure correct operation of the Remote port with the host computer,

set the parameters for the Remote port according to the host computer

requirements.

Note: The default baud rate for computer remote mode is 9600.

Computer Remote Control

ProMaster 2500 User Manual E-3

Remote Mode

Command Set

All remote commands begin with an @ symbol followed by a two-digit

number, with the exception of the reset command (!) and the devices

labeled command (#). After the command is issued, the 2500 responds

with an R followed by two to four ASCII digits and a CR-LF, except in the

case of the Exit Remote and Reset commands, when no response is

returned.

Note: CR-LF means Carriage Return and Line Feed (0D hex and 0A hex). A

CR-LF is sent after every response from the 2500.

All numbers are in decimal, with the individual digits represented in

ASCII, except for the Escape character in the transparent mode command.

Summary of Remote Mode

Command Set

Command Description Response

@@01

Program and label parts - continuous R01

@02

Set up R02

@03

Program and label devices R03

@04 Request firmware version R

XXX

@05 Exit remote mode None

@06

XXX

Set up label placement R06

@07

XXYYY

Bin assignment R07

@08

XXX

Bin label mapping R08

@09

XXX

Serial control functions R09

@10

Transparent mode R10

@11

Label only devices - continuous R11

@12

XXXX

Program and label devices R12

@13

XXYYZZZZ

Variable text mode Varies

@14

Send variable text R14

@15 Download device table Device table

and R15

@16

Retry devices in programming module R16

@17

Define pass category R17

@18 Handler identification R2500

@21 Print only R21

@22 Purge R22

@23X Contact adjust R23

# Request number of devices labeled R

XXXX

! Reset None

* Terminate job R* after last

part is sorted

Computer Remote Control

E-4 ProMaster 2500 User Manual

@@01

Program and Label Parts - Continuous

—where

represents the

maximum parts needed to fill a receiving tube. This is followed by a 2500

hex file.

After the 2500 receives this command and upon detecting devices at the

input, it begins to continuously program and label devices. To invoke a

new command, you must send a ! (the reset command).

Response: R01 (Sent after the hex file is received)

@@02

Set Up —

where

represents the maximum parts necessary to fill a

receiving tube. This is followed by a 2500 hex file.

This command specifies the number of devices to be processed and the

mode of operation, giving the 2500 the information needed to program

and label parts. After the command sequence is received, an @03, @12 or

@13 command is issued and the 2500 starts programming and labeling

immediately upon detecting devices at the input.

Response: R02 (Sent after the hex file is received)

@@03

Program and Label Devices

(1 to 99 devices)—where

represents the

number of devices to program/label.

This command programs and labels devices with the information

provided by a previously sent command, @02. When the specified

number of devices has been labeled, the 2500 responds with an R03 and

waits for another command. You may send as many @03 commands as

you need. If you want to program more than 99 devices, use the @12

command.

WARNING:An @02 command must have been sent previously or

random data will be printed.

Response: R03 (Sent after the devices have been labeled)

@@04 Request 2500 Firmware Version

—where

XXX

in the response from the

2500 represents a three-digit decimal number in ASCII. For example, a

301 response represents firmware version 3.01.

Response: RXXX

@@05 Exit Remote Mode

—Takes the 2500 out of Remote mode. When this

command is issued, the 2500 performs a reset and returns to local mode,

re-enabling the front panel.

@@06

XXX

Label Placement

—where

XXX

represents the label placement value.

This command alters the front to back (lengthwise) placement of the label

on the device. The label placement value is a decimal number between 0

and 254. Each unit moves the label from the leading edge of the device by

0.010 inch. A value of 255 reverts the 2500 to auto centering. This

command remains in effect until power is turned off.

If you do not use this command, the 2500 uses the label placement value

entered in Setup.

Response: R06
