Computer Remote Control

E-4 ProMaster 2500 User Manual

@@01

Program and Label Parts - Continuous

—where

represents the

maximum parts needed to fill a receiving tube. This is followed by a 2500

hex file.

After the 2500 receives this command and upon detecting devices at the

input, it begins to continuously program and label devices. To invoke a

new command, you must send a ! (the reset command).

Response: R01 (Sent after the hex file is received)

@@02

Set Up —

where

represents the maximum parts necessary to fill a

receiving tube. This is followed by a 2500 hex file.

This command specifies the number of devices to be processed and the

mode of operation, giving the 2500 the information needed to program

and label parts. After the command sequence is received, an @03, @12 or

@13 command is issued and the 2500 starts programming and labeling

immediately upon detecting devices at the input.

Response: R02 (Sent after the hex file is received)

@@03

Program and Label Devices

(1 to 99 devices)—where

represents the

number of devices to program/label.

This command programs and labels devices with the information

provided by a previously sent command, @02. When the specified

number of devices has been labeled, the 2500 responds with an R03 and

waits for another command. You may send as many @03 commands as

you need. If you want to program more than 99 devices, use the @12

command.

WARNING:An @02 command must have been sent previously or

random data will be printed.

Response: R03 (Sent after the devices have been labeled)

@@04 Request 2500 Firmware Version

—where

XXX

in the response from the

2500 represents a three-digit decimal number in ASCII. For example, a

301 response represents firmware version 3.01.

Response: RXXX

@@05 Exit Remote Mode

—Takes the 2500 out of Remote mode. When this

command is issued, the 2500 performs a reset and returns to local mode,

re-enabling the front panel.

@@06

XXX

Label Placement

—where

XXX

represents the label placement value.

This command alters the front to back (lengthwise) placement of the label

on the device. The label placement value is a decimal number between 0

and 254. Each unit moves the label from the leading edge of the device by

0.010 inch. A value of 255 reverts the 2500 to auto centering. This

command remains in effect until power is turned off.

If you do not use this command, the 2500 uses the label placement value

entered in Setup.

Response: R06

Computer Remote Control

ProMaster 2500 User Manual E-5

@@07

XXYYY

Y = Bin Assignment

—Configures the bin map for the specified bin.

represents the bin and

YYY

represents the bin configuration number. The

bin number is a two-digit ASCII number from 01 to 04, representing the

bin to be configured. The bin configuration number is a three-digit

decimal number in ASCII which, when converted to binary, represents

the category or categories to be routed to the bin specified. The following

is the bit map:

Bit 0 = Category 1

Bit 1 = Category 2

Bit 2 = Category 3

Bit 3 = Category 4

Bit 4 = Category 5

Bit 5 = Don’t care

Bit 6 = Don’t care

Bit 7 = Don’t care

If the bit is on, the category is mapped to that bin.

For example, sending

@0701010

specifies bin 1 and converts 010 decimal

to 00001010 binary. Bits 1 and 3 are on, so categories 2 and 4 are mapped

to bin 1.

Use this command only when the bin mapping must be changed

dynamically. Under normal conditions, set up the bin map once, using

the Binning menu on the 2500’s front panel.

The changes you make with this command are retained until you send a

new @07 command, make changes using the setup menu under

BINNING, or turn off the power.

Response: R07

@@08

XXX

Bin Label Mapping

—Reassigns the bins that receive labeled devices.

XXX

represents the bin label map number, a three-digit decimal number

in ASCII which, when converted to binary, assigns the bins that receive

labeled devices.

The following is the bit map:

Bit 0 = Label bin 1 if on

Bit 1 = Label bin 2 if on

Bit 2 = Label bin 3 if on

Bit 3 = Label bin 4 if on

Bit 4 = Must be off

Bit 5 = Must be off

Bit 6 = Must be off

Bit 7 = Must be off

For example, sending

@08011

converts 011 decimal to 00001011 binary.

Devices going into bins 1, 2, and 4 are labeled.

Use this command only when you must dynamically change the bin label

mapping. Under normal conditions, set up the bin label map once, using

the Binning menu.

Computer Remote Control

E-6 ProMaster 2500 User Manual

The changes you make with this command are retained until you send a

new @08 command, make changes using the setup menu under

BINNING, or turn off power. Sending an @08255 restores the label

mapping settings to those currently defined in the BINNING setup menu.

Response: R08

@@09

XXX

Serial Control Functions

—where

XXX

represents serial control

functions number.

Note: Use this command only when you control the programming electronics

(PE) through the handler firmware. Data I/O recommends that you write

your CRC driver to communicate directly with the PE using the more

extensive set of commands described on page E-17.

This command determines which commands are sent to the

programming electronics using the serial interface mode. The serial

control functions number is a three-digit decimal number in ASCII

which, when converted to binary, represents the commands sent to the

programming electronics.

The following is the bit map:

Bit 0 = Blank check if on

Bit 1 = Illegal bit test if on

Bit 2 = Program device if on

Bit 3 = Verify device if on

Bit 4 = Don’t care

Bit 5 = Don’t care

Bit 6 = Don’t care

Bit 7 = Don’t care

For example, sending

@09013

converts 013 decimal to 00001101 binary.

When using the serial interface mode to communicate with the

programming electronics, blank check, program device, and verify device

commands are sent.

Use this command only when you must change the serial commands

dynamically. Under normal conditions, set up these commands once,

using the Control Functions menu.

The changes you make with this command are retained until you send

another @09 command, make changes using the setup menu under

Control Functions, or turn power off.

Response: R09

@@10

Transparent Mode

—Puts the 2500’s two serial ports into transparent

mode, so the computer connected to the Remote serial port and the 2500

connected to the Programmer serial port can communicate directly with

each other as if a straight-through cable connected the two.

represents

an escape character, a binary number between 0 and 255, which is sent by

the computer attached to the 2500’s Remote serial port to exit transparent

mode. This is the only way to exit transparent mode besides turning off

the power.

Response: R10 when transparent mode is entered and exited
