Introduction
1-18 3/97 ProMaster 2500 User Manual
Power Requirements
Operating
Requirements
Physical and
Environmental
Operating Voltages
100/110/220/240V ac ±10%
Frequency Range
50 to 60 Hz ±5%
Power Consumption
150 VA maximum
120 Watts maximum
Fuse Rating
5 amp slow blow
3 amp slow blow
100V/120V ac (5A/120V/T)
220V/240V ac 93A/240V/T)
Input Air
80 PSI @ 1.0 CFM (5.5 Bar @ 0.0283 CMM)
External Air Filter
10 micron (not provided with system)
Dimensions
Width: 38 in (96.5 cm)
Height: 26 in (66 cm)
Depth: 19 in (48.26 cm)
Weight
Operating configuration (without PC): 160 lb (72.75 kg)
Shipping (without PC): 240 lb (109.1 kg)
Altitude
Operating: to 49,200 feet (15,000 meters)
Track Width
Continuously adjustable from 0.30 to 1.2 in. (0.76 to 3 cm)
Temperature
Operating Range: 50 to 100.4 degrees F (10 to 38 degrees C)
Storage Range: -36 to +158 degrees F (-20 to 70 degrees C)
Relative Humidity
Operating: to 80% noncondensing
Storage: to 90% noncondensing
Introduction
ProMaster 2500 User Manual 3/97 1-19
Safety (CE units only)
The ProMaster 2500 meets essential health and safety requirements and
conforms to the following European Community (CE) directives:
• Machinery Directive 89/392/EEC
• Electromagnetic Compatibility Directive 89/336/EEC
• EN 292-1,2—Safety of Machinery
• EN 60204-1—Safety of Machinery (Electrical Equipment of Machines)
Certificate of RFI/EMI
Compliance (CE units)
Data I/O certifies that the ProMaster 2500 complies with the Radio
Frequency Interference (RFI) and Electromagnetic Interference (EMI)
requirements of EN55011 Class A, IEC-801-2, -3, and -4, as called out in
89/336/EEC, the EMC directive for the European Community.
WARNING:This equipment is a class A product. In a domestic
environment this product may cause radio interference in
which case the user may be required to take adequate
measures.
Options
Optional Spares Kit
In addition to the Standard Spares Kit included with your ProMaster
2500, an Advanced Spares Kit is available. This kit includes larger
assembly items such as the power supplies, front panel, programming
electronics boards, and controller boards. This kit must be purchased as a
separate item from the Standard Spares Kit.
Keep Current
Subscription Service
Data I/O provides a one-year subscription to keep the 2500 and its
documentation up-to-date with the latest features and device support.
This subscription also incorporates manufacturer-recommended changes
to existing device support for maintaining optimum yields, throughput,
and long-term reliability.
The service includes immediate access to new and updated programming
algorithms via our Keep Current Bulletin Board System (BBS)—before
the algorithms are available in the update kit. Keep Current algorithms
are also available on the Data I/O Home Page on the World Wide Web at
http://www.data-io.com
.
For more information, contact Data I/O Corporate Sales at 800-332-8246.
88-pin Upgrade
An upgrade is available to convert 44-pin programming electronics to 88-
pin capacity to program devices with a higher pin count. Contact
Data I/O Service at 800-735-6070 for more information on this upgrade.
Service Contracts
For information on service contracts, contact Data I/O Service at
800-735-6070.
Introduction
1-20 3/97 ProMaster 2500 User Manual
For More Information
For technical assistance, call the
Data I/O Customer Resource Center
at
800-247-5700
.
(Press 2 on your touch-tone phone to bypass the operator or
recorded message and speak to the first available Support Engineer.)
Call
800-735-6070 Data I/O Service
for information on:
•Service
• Service contracts
• Operator or Service training or retraining
• Ordering spare parts and kits (if you know the correct part numbers)
Call
800-332-8246 Data I/O Corporate Sales
to order any of the following:
• Ribbons and labels
• Update or upgrade information
• Keep Current subscription
