Local Mode
F-4 ProMaster 2500 User Manual
Type Size
After you have selected an existing device or entered a valid length for
your custom device, the 2500 displays:
Select the font you want and press
ENTER
.
The 2500 displays:
Device Orientation in
Input Tube
Move the pin 1 icon (using the arrow keys) to match the position of pin 1
on the device in the input tube. We recommend these settings.
1. For square PLCC devices, orient pin 1 toward the back of the 2500.
2. For 32-pin PLCCs, all DIP, and all SOIC devices, orient pin 1 to the
right (assuming you are standing in front of the 2500).
Note: Make sure the device orientation is the same in the display and in the
input track. If the orientation is not the same, during operation the device
may be inserted incorrectly into the programming module, possibly
damaging the device or programming module.
Press
ENTER
when your selections are completed.
Text Rotation
The 2500 displays:
Select a text rotation and press
ENTER
. We recommend the following
selections:
Orientation in
Receiving Tube
The next display prompts you to select the position of pin 1 as the device
moves into the receiving tube. The 2500 displays:
Use the arrow keys to move the pin 1 icon to match its position on the
device as it enters the receiving tube. Press
ENTER
when you are
satisfied with your selection.
Tip: So that you can place devices back in the 2500 without repositioning them,
choose a setting that places the devices in the receiving tube opposite their
orientation in the input tube.
PRINT LABEL TEMPORARY FILE
AUTO-SEL 26 CPI 26 CPI S 20 CPI
16 CPI T 12 CPI T 18 CPI
MOVE TO SELECTION THEN PRESS ENTER
1 <------- TEMPORARY FILE
SELECT POSITION OF PIN 1
AS IT COMES OUT OF THE TUBE.
USE ARROW KEYS THEN PRESS ENTER.
1 TEMPORARY FILE
SELECT POSITION OF PIN 1
TXT IN RELATION TO THE TEXT.
USE ARROW KEYS THEN PRESS ENTER.
<------- TEMPORARY FILE
SELECT POSITION OF PIN 1
AS IT WILL GO INTO THE TUBE.
1 USE ARROW KEYS THEN PRESS ENTER.
Local Mode
ProMaster 2500 User Manual F-5
Text Content
The TEMPORARY text file is ready to edit when the 2500 displays:
Any text on the left side of the display is from the last file edited and
COLUMN
X
and ROW
X
refer to the position of the cursor.
Up to three lines of text with 25 characters per line are available, but the
number of lines and characters that will fit on a device is limited by the
size of the device, label, and type (font). Enter the text you want on the
label. Existing text is overwritten.
To delete a character, move the cursor one space to the right of the
character you want to delete, and press
DEL
. To insert a space between
two characters, move the cursor to the right of the place you want to add
a space, and press
SHIFT
and
SPACE
at the same time.
When you are finished editing, press
STOP
.
Note: Pressing
RESET
cancels the operation and returns you to the Main
Menu.
Labeling a Device
When the file has been selected, the 2500 displays:
To complete the label only operation follow these steps:
1. Lower the hood.
2. Enter the appropriate number and press
ENTER
. The 2500 displays:
3. Press
START
to begin labeling. The 2500 displays:
The 2500 waits until devices are loaded and then labels devices until none
are available. Press
RESET
to return to the Main Menu.
SAMPLE | TEMPORARY FILE
PROMASTER | COLUMN X ROW X
2500 TEXT | PRESS STOP WHEN
| EDITING IS COMPLETE.
LABEL ONLY FILE NAME: FILE3
ENTER NUMBER OF PARTS PER TUBE (15): _
SAMPLE FILE NAME: FILE
TEXT PART TYPE: PLCC 20
FILE PART LENGTH: .390
123456789 PRESS START TO BEGIN
LABEL ONLY FILE NAME: FILE3
COMM: NO INTERFACE PART TYPE: PLCC 20
PART PER TUBE: 15 PART LENGTH: .390
PART TOTAL = 0 PROGRAM TARGET: INF
Local Mode
F-6 ProMaster 2500 User Manual
Print Only
The Print Only feature enables you to check the position of text on the
label by printing a label without applying it to a device. To use this
feature, perform the following procedure.
1. Press
1
from the Main Menu to select OPERATIONS. The 2500
displays:
2. Press 5 to select PRINT ONLY. The 2500 displays:
Select the file name and press
ENTER
to select it.
3. Select a file to print and press
ENTER
to select it. The 2500 displays:
4. Press
START
to print a label. Catch the label with your finger. Press
RESET
to return to the Main Menu.
Purge
The Purge feature allows you to cycle devices through the system
without programming or labeling them. Use this mode to remove
unwanted devices from the system.
File Utilities Menu
The File Utilities allow you to create, edit, or delete files. From the 2500
Main Menu, press
2
to select FILE UTILITIES. The 2500 displays:
Edit Files
To create and edit files, press
1
. The 2500 displays:
Note: Pressing
RESET
cancels the operation and returns you to the Main
Menu.
* * * OPERATIONS MENU * * *
1 - PROGRAM/TEST & LABEL 4 - LABEL ONLY
2 - LOAD MASTER 5 - PRINT ONLY
3 - PROGRAM/TEST ONLY 6 - PURGE
PRINT LABEL
TEMPORARY FILE1 FILE2 FILE3
FILE4 FILE5 FILE6 FILE7
ENTER FILE NAME:
PRINT LABEL TEMPORARY FILE
AUTO-SEL 26 CPI 26 CPI S 20 CPI
16 CPI T 12 CPI T 18 CPI
MOVE TO SELECTION THEN PRESS ENTER
PRINT LABEL FILE NAME: FILE5
PRESS START TO PRINT
A LABEL
* * * FILE UTILITIES MENU * * *
ENTER THE NUMBER OF THE DESIRED FUNCTION
1 - EDIT FILES 3 - MAIN MENU
2 - DELETE FILES
FILE EDIT MODE
FILE1 FILE2 FILE3 FILE4
FILE5 FILE6 FILE7 FILE8
ENTER FILE NAME TO EDIT:
