Local Mode
F-8 ProMaster 2500 User Manual
Type a filename not currently on the list of files or use the arrow keys to
scroll to files not listed on the display. (Only eight filenames appear on
the screen at one time.)
The 2500 creates the new file and displays:
Since this is a new file, no default values are shown. Enter the device and
text information as described in the section called “Creating the
Temporary File” earlier in this chapter. Press any key (except
RESET
) to
return to the File Utilities Menu.
Delete Files
To select DELETE FILES, press
2
from the File Utilities Menu. The 2500
displays:
Type the name of the file to delete, or scroll to the name and press
ENTER
. The 2500 displays:
Press
Y
to delete the file and the 2500 displays:
Press
Y
to delete another file or press any other key. The 2500 displays:
Press any key other than
Y
to return to the File Utilities Menu.
To return to the Main Menu, press
RESET
or press
3
from the File
Utilities Menu.
FILE EDIT MODE
FILE1 FILE2 FILE3 FILE4
FILE5 FILE6 FILE7 FILE8
ENTER FILE NAME TO EDIT: NEWNAME
FILE EDIT MODE NEW FILE: NEWNAME
CUSTOM PLCC 20 PLCC 28 PLCC 32
PLCC 44 PLCC 52 PLCC 68 PLCC 84
MOVE TO SELECTION THEN PRESS ENTER
FILE DELETE MODE
FILE1 FILE2 FILE3 FILE4
FILE5 FILE6 FILE7 FILE8
ENTER FILE NAME TO DELETE:
FILE DELETE MODE FILE NAME: NEWNAME
DELETE THIS FILE? (Y OR N)
FILE DELETE MODE FILE NAME: NEWNAME
DELETE THIS FILE? (Y OR N) Y
FILE WAS DELETED, DELETE ANOTHER FILE?
FILE DELETE MODE FILE NAME: NEWNAME
DELETE THIS FILE? (Y OR N) N
FILE NOT DELETED, DELETE ANOTHER FILE?
Local Mode
ProMaster 2500 User Manual F-9
System Setup Menu
There are three submenus under System Setup.
General Setup Menu
General setup allows you to change the port settings and choose to turn
the audible alarm on or off. The access these from the 2500 Main Menu,
press
3
to select SYSTEM SETUP.
The 2500 displays:
Press
1
to select the GENERAL SETUP MENU.
Audible Alarm
If the Audible Alarm is enabled, a tone is emitted for every keystroke and
error message. To enable or disable the Audible Alarm, press
1
from the
General Setup Menu. If the alarm is currently enabled, the 2500 displays:
If it is disabled, ON appears instead of OFF. Press
Y
if you wish to toggle
to the other state.
Remote and
Programmer Baud
Rates
To change the baud rate on the Remote Port, press
2
. The 2500 displays:
Press the number corresponding to the baud rate you want to use.
Change the baud rate on the Programmer Port in the same way by
pressing
3
. The 2500 displays:
Select the number next to the baud rate you want to use.
To return to the Main Menu, press
RESET
.
* * PROMASTER 2500 MAIN MENU * *
ENTER THE NUMBER OF THE DESIRED FUNCTION
1 - OPERATIONS 3 - SYSTEM SETUP
2 - FILE UTILITIES 4 - DIAGNOSTICS
* * * SYSTEM SETUP MENU * * *
1 - GENERAL 4 - MAIN MENU
2 - LABELER
3 - HANDLER
* * * GENERAL SETUP MENU * * *
1 - AUDIBLE ALARM 4 - SETUP MENU
2 - REMOTE BAUD RATE
3 - PROGRAMMER BAUD RATE
DO YOU WANT AUDIBLE ALARM OFF?
(Y OR N):
ENTER NUMBER OF REMOTE BAUD RATE
DESIRED (X):
1 - 1200 2 - 2400 3 - 4800 4 - 9600
5 - 19200 6 - 38400
ENTER NUMBER OF PROGRAMMER BAUD RATE
DESIRED (X):
1 - 1200 2 - 2400 3 - 4800 4 - 9600
5 - 19200 6 - 38400
Local Mode
F-10 ProMaster 2500 User Manual
Labeler Setup Menu
This menu allows you to alter parameters which affect the printing of
characters on a label and the application of that label on a device.
Label Calibration
Label calibration determines the distance between the edge of the label
and the first printed character. If characters are not being printed on the
label with the correct spacing from the label’s edge, make sure that the
following have been checked:
• Labels have been calibrated.
• Labeler’s pinch rollers are fully engaged against the drive roller.
• ADC value is correctly set to 200.
Note: When you are running a Task or performing any other handler operation,
it is best to use the Stop command
LOWER CASE
+
C
for this parameter.
To change the current label calibration value from the 2500’s front panel,
put the 2500 in local mode. Press
1
from the Labeler Setup menu.
The 2500 displays:
Use the 2500’s keyboard to change the setting. The range is from 0 to 255.
After entering the desired value, save it by pressing the ENTER key. The
2500 records this value as the new default and returns to the Labeler
Setup menu.
Note: If you change the label calibration value, press the CAL key so that the
ADC optic performs the ADC optic label calibration.
Label Placement
The label placement default setting centers the label on the device.
Change this setting from the 2500’s front panel by first putting the system
in local mode. From the Main Menu, press
3
.
From the Labeler Setup menu, press
2
to select LABEL PLACEMENT.
* * * LABELER SETUP MENU * * *
1 - LABEL CALIBRATION 4 - SETUP MENU
2 - LABEL PLACEMENT
3 - LABEL ADJUST
ENTER LABEL CALIBRATION VALUE (XX):_
* * PROMASTER 2500 MAIN MENU * *
ENTER THE NUMBER OF THE DESIRED FUNCTION
1 - OPERATIONS 3 - SYSTEM SETUP
2 - FILE UTILITIES 4 - DIAGNOSTICS
* * * LABELER SETUP MENU * * *
1 - LABEL CALIBRATION 4 - SETUP MENU
2 - LABEL PLACEMENT
3 - LABEL ADJUST
