Local Mode

ProMaster 2500 User Manual F-11

The 2500 displays:

Enter a number from 0 to 254. Entering a “0” (zero) places the left end of

the label on the leading edge of the device; each unit higher moves the

label 0.010-inches away from the leading edge of the device. Press

ENTER

to accept the selection.

This parameter can also be changed by the system administrator using

TaskLink.

Label Adjust

This is a fine-tune adjustment for the label placement value when it is set

to “autocenter.” To change the value when the 2500 is in the local mode,

go to the Labeler Setup menu and press

The 2500 displays:

Use the 2500’s key pad to change the displayed setting. Increasing the

number moves the label farther from the leading edge of the device.

When you have entered the desired value, save it by pressing

ENTER

The 2500 records this value as the new default and returns to the Labeler

Setup menu.

Note: When you are running a Task or performing any other handler operation,

it is best to use the Stop command

LOWER CASE

for this parameter.

Handler Menu

The items in this menu allow you to alter parameters affecting the

handling of devices on the 2500.

Binning

The binning assignments defined by this command are used to redefine

which output tube on the 2500 will receive the pass and fail devices after

the programming operation. Under normal circumstances these will not

be changed from the factory defaults.

If it should become necessary to change the bin assignments, press

from

the System Setup menu to select HANDLER.

ENTER LABEL PLACEMENT VALUE (X):

ENTER "A" FOR AUTO CENTERING

* * * LABELER SETUP MENU * * *

1 - LABEL CALIBRATION 4 - SETUP MENU

2 - LABEL PLACEMENT

3 - LABEL ADJUST

ENTER LABEL ADJUST VALUE (X): _

* * * SYSTEM SETUP MENU * * *

1 - GENERAL 4 - MAIN MENU

2 - LABELER

3 - HANDLER

Local Mode

F-12 ProMaster 2500 User Manual

The 2500 displays:

Press

. The 2500 displays:

The

in the displays represents the category signal sent by TaskLink (or

any computer remote control driver program) to indicate the result of the

last programming operation. In the example above, a

signal from

TaskLink indicates that the device passed.

BIN 1

represents output tube

holder 1 and

BIN 2

represents output tube holder 2. When TaskLink send

a C1 signal, the 2500’s beam takes the device to the labeler (if the Task has

label selected as part of the current process) and then places that device in

output track 1.

For a device that has had a programming error, TaskLink might be

configured to send a C2 to the 2500. The 2500 would not label the failed

device and would send it to output bin 2, which is output tube 2.

This is the default setting for the binning control setup. Notice that in the

second line for all failures, there is no

after

Label

in the second line of

the display above. If labeling has been selected in the Task, this

unselected option instructs the 2500 not to label a device that has failed. If

you find that the 2500 is labeling failed devices, check to see that someone

has not inadvertently placed an X after Label in the second line. The 2500

will not label passing devices with one label text and failing devices with

different label text.

Control Functions

This command is used in conjunction with the Program/Test Only and

Program/Test and Label commands under the Operations menu. These

commands are used by Data I/O service personnel only and are not

usable under normal operation.

* * * HANDLER SETUP MENU * * *

1 - BINNING

2 - CONTROL FUNCTIONS

3 - SETUP MENU

BIN 1=C1-X C2- C3- C4- C5- LABEL-X

BIN 2=C1- C2-X C3-X C4-X C5-X LABEL-

ndex

ProMaster 2500 User Manual Index-1

Absolute addressing, 3-17

Adapter, air connection, 2-4

ADC optic

adjusting value, 5-34, B-2

adjusting, dot matrix printer, 5-34

adjusting, thermal printer, 5-35

label calibration, 5-7

positioning, 5-7

roller assembly, 5-15, 5-17

super optic collector, A-5

Adjusting

ADC optic, dot matrix printer, 5-34

ADC optic, thermal printer, 5-35

ADC value, 5-34, B-2

dot matrix print head gap, 5-24

dot split, 2-26

label placement, 2-25, 5-25

label print position, 5-25

label print position, thermal printer, 5-26

labels, 5-25

print intensity, thermal printer, 2-29

print quality, dot matrix printer, 2-22

thermal printer, 5-27

track, 5-64

track air, 4-38

track width, 4-12

Air

handler input, 4-17

input requirements, 2-2

Air filter, external, 2-5

Air flow, system, 5-9

Air gauges, setting, 2-7, 4-17

Air input, pressure, 4-17

Air line

adapter, 2-4

connection, 2-5

disconnecting, 2-6

Air pressure

adjusting, 2-7

adjustment knobs, 1-4

recommended settings, 2-5

Alarm, audible, setting, F-9

Algorithm-specific error message, 6-2

Aligning device

to DIP/SOIC/32-pin PLCC module, 4-31

to PLCC module, 4-27

Anti-backlash nut, replacement, 7-24

Antistatic precautions, 4-4

Antistatic wrist strap, 5-50

Application plate, checking the height, 2-9

Attachment, 8-pin 150 mil SOIC device, 4-14

Audible alarm

about, 2-21

setting, F-9

Automatic RAM fill command, 3-18

Auto-Select, 3-11
