Installation and Setup
2-24 ProMaster 2500 User Manual
2. Press
2
to select LABELER. The 2500 displays this menu:
Label Calibration
Label calibration determines the distance between the edge of the label
and the first printed character. This value is set at the factory and does not
usually need to be changed. If the text is not being printed on the label in
the proper location, ensure that the following conditions have been met:
• Labels have been calibrated.
• Labeler’s pinch rollers are fully engaged against the drive roller.
• ADC value is correctly set to 200 (see page 5-34 for this procedure).
• Correct labels for the 2500 (“QF” in the part number) are installed.
If these actions do not resolve the placement problem, you may need to
adjust label calibration.
To change the current label calibration value from the 2500’s front panel,
put the 2500 in local mode. The 2500 displays:
Press
1
from the LABELER SETUP MENU. The 2500 displays:
Use the 2500’s keyboard to change the setting. The range is from 0 to 255.
After entering the desired value, save it by pressing the
ENTER
key. The
2500 records this value as the new default and returns to the LABELER
SETUP MENU.
Note: If you change the label calibration value, press
CAL
so that the ADC optic
performs the ADC optic label calibration (see page 2-11).
* * * LABELER SETUP MENU * * *
1 - LABEL CALIBRATION 4 - SETUP MENU
2 - LABEL PLACEMENT
3 - LABEL ADJUST
Figure 2-15
Changing the Label Calibration
Value
* * * LABELER SETUP MENU * * *
1 - LABEL CALIBRATION 4 - SETUP MENU
2 - LABEL PLACEMENT
3 - LABEL ADJUST
ENTER LABEL CALIBRATION VALUE (XX):_
1944-1
NORMAL
HIGHER VALUE
Installation and Setup
ProMaster 2500 User Manual 2-25
The label calibration value can also be changed while the 2500 is
processing devices using the STOP command. Press
STOP
on the 2500’s
keyboard and then
LOWER CASE
+
C
. The 2500 displays:
where X represents the current setting. Enter a new value (between 0 and
255) on the 2500’s keyboard. Press
ENTER
to save the value.
Press
CAL
to run the ADC optic’s label calibration. When the calibration
has completed, press
START
to continue running the Task.
Label Placement
The label placement value controls the position of the label on the device.
Using the factory default setting (autocenter), the 2500 positions the label
in the center of the device.
You can change this parameter either from the 2500’s front panel or in
TaskLink. To change the value in TaskLink, refer to the
ProMaster
dialog
box on page 3-9.
To change the label placement from the 2500’s front panel, press
2
from
the LABELER SETUP MENU.
The 2500 displays:
where X represents the current setting. Enter a number from 0 to 254 to
change the setting. Entering 0 places the left end of the label on the
leading edge of the device. Each increase in this value moves the label
0.010 inch further away (delayed) from the leading edge of the device.
After entering the value, press
ENTER
to save the new setting.
PROGRAM/TEST LABEL
ENTER LABEL CALIBRATION VALUE (X):_
* * * LABELER SETUP MENU * * *
1 - LABEL CALIBRATION 4 - SETUP MENU
2 - LABEL PLACEMENT
3 - LABEL ADJUST
ENTER LABEL PLACEMENT VALUE (X):_
ENTER “A” FOR AUTO CENTERING
Figure 2-16
Changing the Label Placement
Value
PLACEMENT = 0
PLACEMENT = A
1363-2
LABELLABEL
Installation and Setup
2-26 ProMaster 2500 User Manual
Label Adjust
This is a fine-tune adjustment of the label placement value when it is set
to “autocenter.”
To change the value when the 2500 is in the local mode, press
3
from the
LABELER SETUP MENU.
The 2500 displays:
Use the 2500’s keyboard to change the displayed value. Increasing the
number moves the label farther from the leading edge of the device.
When you have entered the desired value, save it by pressing
ENTER
.
The 2500 records this value and returns to the LABELER SETUP MENU.
To change this setting while the 2500 is running a Task, press
STOP
and
then
LOWER
CASE
+
A
. The 2500 displays:
Enter the new value on the 2500’s keyboard, and then press
ENTER
to
save the value. Press
START
to continue the Task and check the next
device.
Dot Split Value
This setting is adjusted at the factory and should not need to be changed
unless you need to adjust print quality. If the vertical strokes on your
label characters are fuzzy you may need to adjust the dot split value. Any
change in this value affects all the character fonts.
To check or adjust the split value, follow the steps below.
1. Create a label file using the letter E in the 20 font.
2. Select the PRINT ONLY command in the local mode (see page 2-22).
3. Press
LOWER CASE
+
S
while in Print Only mode.
* * * LABELER SETUP MENU * * *
1 - LABEL CALIBRATION 4 - SETUP MENU
2 - LABEL PLACEMENT
3 - LABEL ADJUST
ENTER LABEL ADJUST VALUE (X): _
PROGRAM/TEST LABEL
ENTER LABEL ADJUST VALUE (X): _
Figure 2-17
Changing the Dot Split Value
PRINT LABEL
ENTER DOT SPLIT VALUE (XX): _
1938-2
NORMALBLURRED TEXT
