P-247-006e - 第47页
G -S050-07 1012-003 45 Key No. P AR T No. P AR T NAME Q’ty REMARKS New Code NOTE D-1 4 6301281650 PLA TE 4→3 803D--210-104 21 1D9700 5 6301360652 PLA TE 4→3 803D--210-105 21 1DA514 14 6301272078 BLOCK 4→3 803D--210-1 14 …
G -S050-07
0909-002
44
33
31
32
35
22
14
4
5
EXCHANGE
EXCHANGE
EXCHANGE
EXCHANGE
5
4
14
22
多機能ヘッド取付
Main Machine Modification(Left-Rear,Right-Front)
本体対応（左奥、右前）
For Attaching Multi-Functional Head
G -S050-07(GXH-1,1S) G -S050-07(GXH-1,1S)
Fig. D-1
部品認識部 - 部品認識カメラ
Recognition Section-Recognition Camera
G -S050-07
1012-003
45
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
D-1
4 6301281650 PLATE 4→3 803D--210-104 211D9700
5 6301360652 PLATE 4→3 803D--210-105
211DA514
14 6301272078 BLOCK 4→3 803D--210-1
14 211G3532
22 6301246598 LIGHTING UNIT 4→3 803D--210-202
4Z110137
31 6301265377 PLATE(STANDARD MARK) 1
803D-A210210-A001
211D9577
32 6301314426 PLATE 1
803D-A210210-A002
211D9985
33 6301314310 BLOCK 1
803D-A210210-A003
211G3745
35 6301270265 LIGHTING UNIT 1
803D-A210210-A005
4Z110147
G -S050-07
0909-002
46
See Fig.FC-3
Key No.261
197
196
196
See Fig.FB-2
Key No.164
197
198
DELETE
EXCHANGE
For Left-Rear
多機能ヘッド取付
Main Machine Modification(Left-Rear,Right-Front)
本体対応（左奥、右前）
For Attaching Multi-Functional Head
G -S050-07(GXH-1,1S) G -S050-07(GXH-1,1S)
Fig. BF-2
架台下
XY
サーボ部 - ケーブル
L Underframe XY Servo section-Cable L
